- Page 1 INSTRUCTION MANUAL EHP700LU Battery-powered Pump Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 52062960 REV 1 © 2013 Greenlee Textron Inc. 9/13...
-
Page 2: Table Of Contents
All specifications are nominal and may change as design improvements occur. GreenleeTextron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. KEEP THIS MANUAL Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 3: Important Safety Information
Automatic shut off may not work. Failure to observe this warning will result in severe injury or death. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 4 Failure to wear eye protection could not allow the accessory’s ram to retract after the result in serious eye injury from flying hydraulic operation is finished. debris or hydraulic oil. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 5 Failure to observe this precaution may result in injury and property damage. Note: Keep all decals clean and legible, and replace when necessary. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 6: Identification
Maximum Operating Pressure ............10,000 psi (700 bar) Operating Temperature Range ........10 °F to 104 °F (-12°C to 40 °C) Dual-Stage Pumping Action Rapid Advance .....................0.9 l/min At Full Pressure ....................0.3 l/min Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 7: Features Of The Pump
To change the units, set the selection switch to 7, depress the pendant toggle three times, and then hold the toggle switch to change the display. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 8: Operation
2. Press down on the manual release shaft and allow the ram to retract fully. 3. Disconnect the hose slowly to release any trapped pressure. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 9 Note: The retraction button of the forward and return not running. switch is always active and can be actuated at any time and in any program. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 10: Maintenance
Failure to observe these warnings could result in severe injury or death. Relief valve adjustments must be done by an authorized service center. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 11: Troubleshooting
LED glows for 20 Battery charge low. Charge or replace battery. seconds. Tool loses oil. Damaged internal seal. Return tool to a Greenlee Utility Authorized Service Center. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 12: Illustrations And Parts Lists
EHP700LU Battery-powered Pump Illustration—Main Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 13: Motor
Seal kit (includes items marked with † ) Screw ............1 52062239 Fastener kit (includes items 52062228 Adapter ..........1 marked with * ) 52062194 Coupler, 3/8 female .......1 52062241 Coupler cap ..........1 Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 14: Release Lever
T = 1.5 Nm max. Part No. Description 52062196 Release lever unit Release lever.........1 Screw ............1 Compression spring ......1 Bolt............1 Nut ............1 T = 1.5 Nm max. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 15: Pump Housing Unit
Valve seat ..........1 8† O-ring ............1 † 52062238 Seal kit (includes items marked with † ) 52062239 Fastener kit (includes items marked with * ) Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 16: Relief Valve
Screw plug ..........1 3† Piston seal ..........1 4† Washer ..........1 Pump piston..........1 Valve stem ..........1 Spring ...........1 † 52062238 Seal kit (includes items marked with † ) Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 17: Reservoir Assembly
Contact cover ........1 Contact board ........1 Screw ............4 Washer ..........4 Standoff ..........4 52062239 Fastener kit (includes items marked with * ) T = 1.5 Nm Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 18: Control Unit
Control shaft .........1 Screw ............6 LCD display ..........1 Board ............1 52062216 Switch ...........1 Pin ............1 Retaining ring ........1 52062239 Fastener kit (includes items marked with * ) Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 19 EHP700LU Battery-powered Pump Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 20 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 USA Tel: 800-435-0786 Canada Tel: 800-435-0786 International Tel: +1-815-397-7070 An ISO 9001 Company • Fax: 800-451-2632 Fax: 800-524-2853 Fax: +1-815-397-9247 Greenlee Textron Inc. is a subsidiary of Textron Inc. www.greenlee.com...
