Chapter 3. Product Description
4) Display / ISE-170C, ISE-170L
④
⑤
⑥
Name
Program display
Memory
Gear ratio display
Display for direction of rotation
Optic LED Display
Error display
Torque display
Speed display
Coolant display
① ②
Indicates function being used during surgery.
Memory indicates the number of saved set value in using it.
Indicates gear ratio currently selected for use.
Indicates direction of motor's rotation and flickers during
Indicates the status of the motor LED.
Error indicates the corresponding number of error upon its
Indicates the set torque value upon operation stand-by and the
ratio of actual load torque compared to set torque value during operation.
Indicates the set rotation speed upon operation stand-by
and the actual rotation speed during operation.
Indicates injection a mount of water in 5 levels.
7/24
③
Function
operation of engine.
occurrence.
