Chapter 5. Operation
5.3 Memory function
5.3.1 Memory number
M
Memory
Button
※ Initial setting (Factory settings) : Memory
Program
Drilling
Tapping
Remove tap
Implant
Remove
Lock screw
5.3.2 Saving data
S
System
Button
It loads memory address where detailed figures (Gear ratio, Torque,
Speed, For/Rev, Coolant) of each function in program are saved.
Memory address alters in turn from number 1 to 9 upon pressing
Memory button each time.
LCD DIsplay
Gear ratio Torque[Ncm]
20:1 55
20:1
40
20:1 40
20:1 40
20:1 55
20:1 10
It saves detailed figures in memory which are currently set
(Gear ratio, Torque, Speed, For/Rev, Coolant) for each function in program.
Press and hold the memory button for 2 seconds and the border with the
memory number flashes along with a beep.
Press the memory button to select a memory address to store the number,
and press the system button for 2 seconds, the frame with the memory
number will flash alternately, and the frame will be off with a beep sound,
then the saving is complete.
Memory1 Memory2
① Drilling ① Drilling
set value
set value
② Tapping ② Tapping
set value set value
③ Remove tap
③ Remove tap
set value set value
④ Implant ④ Implant
set value set value
⑤ Remove ⑤ Remove
set value set value
⑥ Lock screw ⑥ Lock screw
set value set value
Speed[rpm] Motor diriection
1,500 Foward
50 Foward
50 Reverse
50 Foward
50 Reverse
50 Foward
15/24
Memory3
① Drilling
set value
② Tapping
set value
③ Remove tap
set value
④ Implant
set value
⑤ Remove
set value
⑥ Lock screw
set value
Coolant level
4
3
3
3
0
0
