MicroNX ELEC ENGINE SE-170C Instructions For Use Manual

Dental engine for implant surgery
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTRUCTIONS FOR USE
Dental Engine for Implant Surgery / ISE-170C, ISE-170L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELEC ENGINE SE-170C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MicroNX ELEC ENGINE SE-170C

Summary of Contents for MicroNX ELEC ENGINE SE-170C

  • Page 1 INSTRUCTIONS FOR USE Dental Engine for Implant Surgery / ISE-170C, ISE-170L...
  • Page 2 Symbols Federal law restricts this device to sale by or the order of a dentist Catalogue number Serial number Manufacturer Authorized representative in the European Community Date of manufactured BF type applied part Alternating current Keep dry Caution Consult Instruction for use Do not dispose of with domestic waste Water proof grade IPX1...

  • Page 3: Table Of Contents

    Contents Chapter 1. Overview Chapter 2. Safety Chapter 3. Product Description Chapter 4. Installation Chapter 5. Operation Chapter 6. Maintenance Chapter 7. Trouble Shootings Chapter 8. Accessories and Service Chapter 9. Electromagnetic Compatibility Chapter 10. Disposal 2/24...

  • Page 4: Chapter 1. Overview

    Chapter 1. Overview 1.1 Operating Principle This device is an unit that consists of a main body, BLDC (brushless DC) motor, and foot pedal switch for driving and operating a handpiece for dental implant procedures, to be used in dentistry in the field of implant surgery.

  • Page 5: Chapter 2. Safety

    Chapter 2. Safety (Warnings and Cautions) 2.1 Danger 1) When cause of abnormality is not detected or abnormality is not easily solved, contact the head office immediately. 2) When the display is wrongly shown, make inquiries to the head office. It is at risk for accident. 3) Do not bring any patient into contact with signal input section or signal output section and other connections.
  • Page 6 Chapter 2. Safety 2.3 Caution 1) When any abnormality such as vibration, heat and strange sound is detected before or during use, stop using the product immediately and examine it. 2) Prepare extra consumables in using the product. 3) Ensure that speed which is recommended by the manufacturer is maintained on tools used for implant surgery.

  • Page 7: Chapter 3. Product Description

    Chapter 3. Product Description 3.1 Description of System, Components and Functions 3.1.1 Main Controller 1) Front Irrigation fixing part GEAR RATIO Display FOR/REV Irrigation device switch PUSH COOLANT Motor connection TORQUE SPEED 2) Rear Power cord connection part Irrigation hanger connection part Power switch Foot switch connection part 3) Pannel...
  • Page 8 Chapter 3. Product Description 4) Display / ISE-170C, ISE-170L ① ② ③ ④ ⑦ ⑤ ⑧ ⑥ ⑨ Name Function Program display Indicates function being used during surgery. Memory Memory indicates the number of saved set value in using it. Gear ratio display Indicates gear ratio currently selected for use.
  • Page 9 Chapter 3. Product Description 3.1.2 Foot switch (FS-V1) Foot switch cable Foot switch connector Hanger hole Coolant button Rotation button Program button Operation button 3.1.3 Motor (ISM-B70L) Optic LED Handpiece connection Motor connection 8/24...
  • Page 10 Chapter 3. Product Description 3.2 Product Performance 1) Main controller (ISE-170C / ISE-170L) Power Supply Voltage 100-120/220-240 V Frequency 50/60Hz Power Consumption 150VA Max. Coolant flow rate 130 ml/min Fuse 2 × T2AL 250V Dimension 300×230×135 ㎜ [Width×Length×Height] 2) Motor (ISM-B70L) Speed 200 ~ 40,000 rpm Max.
  • Page 11 Chapter 3. Product Description 3.3 Classification of Device 3.3.1 Type of protection against electric shock ClassⅠ equipment 3.3.2 Degree of protection against electric shock Type BF applied part : 3.3.3 Mode of operation Continuous operation 3.3.4 Applied parts Handpiece: Used in connection with a micromotor ※...

  • Page 12: Chapter 4. Installation

    Chapter 4. Installation 4.1 Installation of hanger and Foot switch hanger 4.1.1 Installation of hanger ① Insert Irrigation Hanger into Hanger hole. ② Fix by connecting Hanger bolt. 4.1.2 Installation of Foot switch hanger ① Insert Foot switch hanger into Hanger hole. ②...
  • Page 13 Chapter 4. Installation 4.3 Installation of irrigation tube Spray Clip Irrigation tube ① Attach the irrigation tube to the straight or contra-angle handpiece. Irrigation tube Tube clip Irrigation tube Tube clip ② Attach the motor cable and irrigation tube in regular intervals using the coolant clip. PUSH ③...
  • Page 14 Chapter 4. Installation ③ Close the tube clip. ④ Open the tube clamp before start-up. Tube clip Coolant container ① Attach the irrigation tube to the straight or ① Stick the insert needle into the coolant container. contra-angle handpiece. ② Hook-in the coolant container on the bottle holder. Insert needle 4.4 Connection of power cord and foot switch ①...

  • Page 15: Chapter 5. Operation

    Chapter 5. Operation 5.1 General use ① Turn on the Power switch of implant engine controller. ② Programs are selected in turn by pressing Foot switch or Program button of implant engine controller. ③ Check the displayed Torque, Speed, Coolant, Gear and Direction of rotation. ④...
  • Page 16 Chapter 5. Operation 5.3 Memory function 5.3.1 Memory number It loads memory address where detailed figures (Gear ratio, Torque, Speed, For/Rev, Coolant) of each function in program are saved. Memory address alters in turn from number 1 to 9 upon pressing Memory Memory button each time.
  • Page 17 Chapter 5. Operation 5.4 LED On/Off Press Optic/Non optic button to operate LED within the motor ISM-B70L which is designed for Optic. LED On/Off Button 5.5 Gear ratio change It selects gear ratio in accordance with that on handpiece. Gear ratio alters upon pressing Gear ratio button each time. GEAR RATIO Gear Ratio : Gear ratio...
  • Page 18 Chapter 5. Operation 5.8 Change in torque value (Main function) Torque section on the display flickers upon pressing torque button. Torque is controlled using the button for adjusting set value. TORQUE Torque setting mode is released upon pressing Torque button again Torque or another button on other function or when the motor operates.
  • Page 19 Chapter 55. Operation 5.10 Thread cutting function Activating the thread cutting function is only possible with the Tapping program. LCD Display ① Forward rotation ② Reverse rotation ③ Rotation stop ④ Forward rotation When loading When foot switch off When foot switch on beyond the preset torque limit value 5.11 Auto Calibration...

  • Page 20: Chapter 6. Maintenance

    Chapter 6. Maintenance 6.1 Manual cleaning 1) Separate the motor and Foot Switch connected in the Control Unit. 2) Prepare a cloth (preferably cotton) or soft brush moistened with isopropyl alcohol. 3) Clean foreign substance on the entire surface and in the gaps with cloth or brush soaked in isopropyl alcohol for at least 2 minutes.

  • Page 21: Chapter 7. Trouble Shootings

    Chapter 7. Troubleshooting 7.1 Description of Error Message 7.1.1 Error list Code Status Cause of error Remedy Defective motor hall sensor, Error on motor sensor Asking for repair poor connection Defective motor and Reconnecting and checking the motor Motor error poor connection Asking for repair Restart after turning off the power and...

  • Page 22: Chapter 8. Accessories And Service

    Chapter 8. A / S 8.1 Accessories Motor Connection Cable Motor for Engine (ISM-B70L) Foot Switch (FS-V1) Irrigation Hanger Foot Switch Cable Power Cable Foot Switch Hanger Irrigation tube Tube Holder Hanger Bolt INSTRUCTIONS FOR USE Dental Engine for Implant Surgery / ISE-170C, ISE-170L Motor cap for autoclave Stand Instruction for use...

  • Page 23: Chapter 9. Electromagnetic Compatibility

    Chapter 9. Electromagnetic Compatibility 9.1 Electromagnetic Emission The product is suitable for use in an specific electromagnetic environment. The customer and/or the user of the product should assure that it is used in an electromagnetic environment as described below. Emission Test Compliance Electromagnetic Environment Guidance The product use RF energy only for its internal function.
  • Page 24 Chapter 9. Electromagnetic Compatibility Electromagnetic Immunity Test IEC 60601- Level Compliance Level Environment Guidance 0% U 0% U Voltage dips, Mains power quality should be that of for 0.5 cycle, for 0.5 cycle, short a typical commercial and/or hospital environment. at 0°,45°,90°,135°, at 0°,45°,90°,135°, interruptions and...

  • Page 25: Chapter 10. Disposal

    Chapter 10. Disposal 10.1 Disposal guideline 10.1.1 Disposal of Main controller and foot switch and motor ▶ Follow your country specific laws, directives, standards and guidelines for the disposal of used electrical devices. ▶ Ensure that the parts are not contaminated on disposal. 10.1.2 Disposal of the packaging material ▶...
  • Page 26 The EU directive 93/42/EEC was applied in the design and production of this medical device. 22, Maeyeo-ro 1-gil, 41059 Republic of Korea Tel: 82 53 650 1000 Fax: 82 53 650 1001 Web: www.micronx.co.kr Karl-Marx-Str. 6 16540 Hohen Neuendorf Germany Tel: 49 (0)3303 5412323 Fax; 49 (0)3303 5412324 USM15067-02 2020.

This manual is also suitable for:

Elec engine ise-170l
