Chapter 3. Product Description

3.1 Description of System, Components and Functions
3.1.1 Main Controller
1) Front
Display
2) Rear
Power cord connection part
3) Pannel
Program button
Memory button
System button
Torque button
P
M
S
TORQUE
Irrigation hanger connection part
Power switch
P
M
S
TORQUE
Control Button
6/24
GEAR RATIO
FOR/REV
PUSH
COOLANT
SPEED
Foot switch connection part
GEAR RATIO
FOR/REV
COOLANT
SPEED
Irrigation fixing part
Irrigation device switch
Motor connection
Gear Ratio button
Rotation button
Coolant button
Rotation Speed Button
