KITCHEN KIT BA02-11G Instructions

Drawer Instructions
Parts
Right Hand Bracket
Left Hand Bracket
x 1
x3
T
Softclose Arm
Euroscrews
x 12
R 16mm S
N 15mm Screws
x 54
Assembly
1
Stand base panel upright to
mark and fit drawer sides
using 15mm screws
!
Standing the drawer
upright ensures it's square
4
6
Loosen left and
right-hand side to
adjust
BA02-11H
x 1
RH Drawer runner x 3
D
x3
LH Drawer runner x 3
E
RH Drawer side x 3
F
LH Drawer side x 3
G
Drawer back x 3
H
x6
Drawer base x 3
I
Softclose Housing x 6
J
x 12
10mm
2
Lie the drawer down
to mark and fit the backpanel
using 15mm screws
5
7
Use remaining hole on metal runner
to locate and fit softclose arm,
use 15mm screws
DOCU0039
E H
G
F
I
3
D
J
Top
