3. Front Panel Function Control Description

3.1 Front Panel Hardware Controls
Power Switch
Power LED (Front Head)
Front Panel Controls (Head)
[ 1 ] [ 2 ] [ ] [▲] [▼]
Reaction Time
3.2 Short Cuts Function from the button
[1]
[2]
[▼]
[▲]
[▼]+ [▲]
ViewSonic Corporation
AC Power Switch on the back cover
Soft Power Switch on the front bezel
Blue – ON
Amber – Active Off
Dark = Soft Power Switch OFF
[ ] Power
[ 1 ] Button 1
[ 2 ] Button 2
[▲] Up arrow button
[▼] Down arrow button
Note: Power Button, Button 1 and Button 2
must be one-shot logic operation. (i.e. there
should be no cycling)
OSD must fully appear within 0.5s after
pushing Button 1
Main Menu
(refer to segment 4-6-3)
Input toggle (Analog or DVI or HDMI; refer to refer to
EDID Text)
To immediately activate Audio Adjust menu.
To immediately activate Contrast / Brightness OSD
Menu.
1. In the Audio mode, recall both of Volume and Mute
to default without OSD message.( Under Volume
adjust sub-menu, recall Volume to default without
OSD message.)
2. In the BT / CR mode, recall both Contrast and
Brightness to default in its menu without OSD
message. (Under Contrast or Brightness adjust
sub-menu, recall Contrast or Brightness to its default
without OSD message.)
* While OSD menu off, recall CR/ BT/ Audio volume
