Intellisystem IT-600-IPC Series User Manual page 126

Video level meter
Zoom Image
Snapshot, Video
record and playback
HDMI IN
*(Optional)
HDMI output
RJ45 cable TDR test
12V/2A power output
USB 5V power
output
PoE power output
Screen management
Theme
drop-down menu
Audio test
PTZ control
Color bar generator
PEAK video signal level, SYNC signal level, COLOR BURST chroma
level measurement for cvbs camera.
Supports Analog and IP camera image zooming & movement
Capture current images and record live video as JPG file. Media player
will view photos and playback video
HDMI IN，Support 720×480p /720×576p /1280×720p /1920×1080p
/1024×768p/1280×1024p /1280×900p /1440×900p。
1 channel HDMI output, supports up to 1080p
RJ45 cable TDR test and cable quality test, to test cable pair status,
length, attenuation reflectivity, impedance, skew and other parameter.
Output DC12V/2A power to camera
5V 2A power output only ,NO data
48V PoE power output, Max power 24W
Lite mode and normal model available. Under normal mode, you can
change icons sequence and self-define the number of icons in each page
Self-define icons, desktop and application interface background, modify
interface sliding effect
PoE power switch ,IP setting, WLAN switch , HDMI IN functions etc
screen lock, password lock screen or pattern lock
1 channel audio signal input and 1 channel audio signal output to connect
headphones
SupportRS485 control, Baud 600-115200bps, Compatible with more
than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan,
etc
Output one channel PAL/NTSC color bar video signal for testing
monitor or video cable.(red, green ,blue, white and black color )
