Intellisystem IT-600-IPC Series User Manual page 11

The power indicator: it lights green while the tester is powered on by the
20
adapter
Top interface
Bottom interface
21 Visible red laser source emits Interface (Optional)
22 DC12V2A power output , for provisional DC power supply
23 HDMI IN (Optional )
CVBS IN/AHD /TVI/CVI Coaxial interface / （ BNC interface ） (AHD /TVI/CVI
24
(Optional) )
25 Video signal output（BNC interface）/ cable tracer interface
26
Optical power meter interface (Optional)
27 LED lamp
28 RS485 Interface: RS485communication for the PTZ
6
