ACTiSYS ACT-IR2002UL User Manual

Irready fir usb adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

921 Corporate Way, Fremont, CA 94539, USA
Tel: +1-510-490-8024, Fax: +1-510-623-7268
Web: http://www.actisys.com, E-mail: irda-info@actisys.com
ACT-IR2002UL/ACT-IR4002US
TM
IrReady
FIR USB Adapte
r
User's Manual
ACT-IR2002UL
ACT-IR4002US
April 7, 2014
Version. 1.0.6
©
Copyright 2002-2014 ACTiSYS Corporation,
All Rights Reserved
Warning! Please Install Driver BEFORE you
plug in the Dongle to USB port, for MAC & all
Windows OS unless your PC is Windows 7 or
8 which is plug and play already.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACT-IR2002UL and is the answer not in the manual?

Questions and answers

Related Manuals for ACTiSYS ACT-IR2002UL

Summary of Contents for ACTiSYS ACT-IR2002UL

  • Page 1 921 Corporate Way, Fremont, CA 94539, USA Tel: +1-510-490-8024, Fax: +1-510-623-7268 Web: http://www.actisys.com, E-mail: irda-info@actisys.com ACT-IR2002UL/ACT-IR4002US IrReady FIR USB Adapte User’s Manual ACT-IR2002UL ACT-IR4002US April 7, 2014 Version. 1.0.6 © Copyright 2002-2014 ACTiSYS Corporation, All Rights Reserved Warning! Please Install Driver BEFORE you plug in the Dongle to USB port, for MAC &...
  • Page 2 Serial Number Date of Purchase Place of Purchase All indicated copyrights and trademarks in the following pages are the properties of their respective owners. © Copyright 2002-2014 ACTiSYS Corp. Page 2 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 3: Table Of Contents

    IRCOMM2K DRIVER AND THE VIRTUAL COM PORT ................22 TROUBLE SHOOTING............................25 SPECIFICATION ..............................26 PRECAUTIONS................................ 28 WARRANTY INFORMATION ..........................29 CONTACT INFORMATION ..........................30 © Copyright 2002-2014 ACTiSYS Corp. Page 3 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 4: Revision History

    ACTiSYS reserves the right to make changes without further notice to any products herein to improve reliability, function or design. ACTiSYS does not assume any liability arising out of the application or use of any product or circuit described herein.
  • Page 5 ACT-IR2002UL/ACT-IR4002US User’s Manual The Infrared Wireless Expert respective owners. © Copyright 2002-2014 ACTiSYS Corp. Page 5 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 6: Introduction

    USB port. ACT-IR4002US is the thumb size version of ACT-IR2002UL. The latter has build in USB cable while the former, like a flash disk, has only build in USB connector so that it becomes more compact to be carried.

  • Page 7: Driver Installation For Windows Xp/2000/Me/98Se

    Bubble Window : “Found New Hardware” as shown in the figure. Then this bubble window will show “USB-Infrared Adapter” after completing this procedure. © Copyright 2002-2014 ACTiSYS Corp. Page 7 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 8: Driver Installation For Windows 8/7/Vista (32 & 64 Bit)

    The Installer will install the driver. After this step completes, you will see “Completed” window. Please click Finish to close it. © Copyright 2002-2014 ACTiSYS Corp. Page 8 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...
  • Page 9 ACT-IR4002US It will pop up a Bubble Window : “Installing device driver software”, which will display as “USB-Infrared Adapter” after installed successfully as right figure. © Copyright 2002-2014 ACTiSYS Corp. Page 9 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 10: Driver Installation For Mac Os Intel Based Pc

    ACT-IR2002UL/ACT-IR4002US User’s Manual The Infrared Wireless Expert 7 DRIVER INSTALLATION FOR MAC OS INTEL BASED PC Please install driver BEFORE you plug in ACT-IR2002UL / ACT-IR4002US IMPORTANT: to USB port. Insert the CD, Double click the package file MCS7780DriverDisk. for installing the...
  • Page 11 Click “install” to proceed further. A message window pops up informing that the system requires you to restart the system after the installation. Press “Continue Installation” © Copyright 2002-2014 ACTiSYS Corp. Page 11 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...
  • Page 12 ACT-IR2002UL/ACT-IR4002US User’s Manual The Infrared Wireless Expert Click on “Restart” to finish installing the driver. This completes the Installation of the driver. © Copyright 2002-2014 ACTiSYS Corp. Page 12 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 13: Check Driver Installation In Windows 8/7/Vista/Xp/2000/Me

    8 CHECK DRIVER INSTALLATION IN WINDOWS 8/7/VISTA/XP/2000/ME From Device Manager, you can see “USB-Infrared Adapter” under “Infrared devices. This confirms correct detection of ACT-IR2002UL/IR4002US. Device Manager under Windows XP Device Manager under Windows 8/7/Vista © Copyright 2002-2014 ACTiSYS Corp. Page 13 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 14: Check Driver Installation In Mac Os

    On successful installation, "com.mosChip.driver.moschipIrDA" can be seen in the loaded driver. 10 DRIVER UN-INSTALLATION FOR WINDOWS XP  IMPORTANT: Please keep ACT-IR2002UL/ACT-IR4002US plugged into the computer until prompted to remove it. 1. Open the Control Panel and select Add or Remove Programs.
  • Page 15 Yes button to u ninstall ACT-IR2002UL / ACT-IR4002US Adapte 4. It will start the Uninstallation. It will then finish/exit without any further user action. © Copyright 2002-2014 ACTiSYS Corp. Page 15 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 16: Driver Un-Installation For Windows 8/7/Vista (32 & 64 Bit)

    2. It will ask you to confirm this step. Answer Yes. 3. Then it will complete the Uninstallation. Click Finish to close the window. © Copyright 2002-2014 ACTiSYS Corp. Page 16 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 17: Driver Un-Installation In Mac Os

    Move to Trash) Finder Current Partition Library ---> Receipts MCS7780DriverDsk.pkg (Delete the file / Move to Trash) 3. Reboot the system to complete the un-installation procedure. © Copyright 2002-2014 ACTiSYS Corp. Page 17 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 18: Manually Update The Driver In Windows Xp/ Vista /7 / 8

    Now, as shown in below figure 2 select second option “ Yes, this time only” and Click “Next” Figure 2: Hardware Update Wizard. 3) Now select the option “Install from a list or specific location (Advanced)” and click “Next”. © Copyright 2002-2014 ACTiSYS Corp. Page 18 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...
  • Page 19 4) Select “Don’t Search. I will choose the driver to install” and click “Next”. Figure 4: I will choose the driver to install 5) Select “Infrared devices” as Hardware Type and click “Next”. © Copyright 2002-2014 ACTiSYS Corp. Page 19 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...
  • Page 20 Figure 6: Select Infrared Device 7) Now give the location of the driver path. This path depends on where you keep the file for Windows OS (i.e. from the ACT-IR2002UL/40002US CD or your local machine). After selecting new path, click OK.
  • Page 21 “Completing the Hardware Update Wizard” like as below Figure 8: Updated successfully 9) Finally, check Device Manager for new updated driver as shown in below figure © Copyright 2002-2014 ACTiSYS Corp. Page 21 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 22: Ircomm2K Driver And The Virtual Com Port

    Figure 9: Check Device Manager for updated driver 14 IrCOMM2K DRIVER AND THE VIRTUAL COM PORT If you are using USB or serial IrDA device (e.g. ACT-IR2002UL, ACT-IR4002US, ACT-IR2000UL, ACT-IR4000US, ACT-IR220L+) with Windows 2K or above OS and want to access IrDA...
  • Page 23 You can set the driver properties if required. See detail (http://www.ircomm2k.de/English/manual.html#Install at the end). 4. Go to Control Panel, click "Wireless Link".like above figure. © Copyright 2002-2014 ACTiSYS Corp. Page 23 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...
  • Page 24 7. Connect opposite IrCOMM supported device (i.e. PDA, Palm Hot sync, Handheld, etc..) and align IR eye and start data transfer. If you face any problem or technical question, please contact ACTiSYS Technical Support Team (tech-support@actisys.com) NOTE1:...

  • Page 25: Trouble Shooting

    Please refer to Chapter: – getting some yellow color correctly. MANUALLY UPDATE THE exclamation sign (i.e. “ ”) DRIVER IN XP/VISTA / beside USB Device. WINDOWS 7/8 © Copyright 2002-2014 ACTiSYS Corp. Page 25 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...

  • Page 26: Specification

    4.75 5.25 Stand By (Plug-In Non Active) ACT-IR4002US Active (Receiving) 22.6 Active (Transmitting)  Dimension: Units ACT-IR2002UL (build-in USB cable excluded.) / 62 (2.44) 36 (1.42) 19 (0.75) mm (in.) (build in USB cable included) /1245 (49) ACT-IR4002US 47 (1.85) 18 (0.71)
  • Page 27 ACT-IR2002UL/ACT-IR4002US User’s Manual The Infrared Wireless Expert  Weight: Weight Units ACT-IR2002UL (build in cable included.) 45.6 (1.6) g (Oz) ACT-IR4002US (USB cable excluded) 6.0 (0.2) g (Oz)  Operating Temperature: 0° C to 60° C  Storage Temperature: -20° C to 85° C ©...

  • Page 28: Precautions

     Never touch the pins of computer connection terminal. An Electro Static Discharge can damage the internal circuits. If this device requires any servicing, use only an ACTiSYS service dealer, an ACTiSYS approved service facility, or an ACTiSYS repair service.

  • Page 29: Warranty Information

    The Infrared Wireless Expert 18 WARRANTY INFORMATION ACTiSYS Corporation warrants the first end-user purchaser, for a period of 1 year from the date of purchase, that this wireless interface (The Product) will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof at no charge to the purchaser for parts or for labor.

  • Page 30: Contact Information

    User’s Manual The Infrared Wireless Expert 19 CONTACT INFORMATION ACTiSYS Corporation 921 Corporate Way Fremont, CA 94539, USA TEL:+1-510-490-8024, FAX:+1-510-623-7268 E-Mail: irda-info@actisys.com Web: http://www.actisys.com © Copyright 2002-2014 ACTiSYS Corp. Page 30 of 30 Apr. 7, 2014 ACTiSYS Confidential Information V.1.0.6...
