- Page 1 Gira HomeServer/FacilityServer RemoteVisu Gira HomeServer 0529 00 Gira FacilityServer 2075 00...
-
Page 3: Table Of Contents
Contents Introduction ................... General Information..................Operating devices................... System requirements ..................Area of application ..................Specifics ......................Installation ...................... RemoteVisu.................... Sample project ....................2.1.1 Scope of sample project................. Start-up......................2.2.1 Setup ......................2.2.2 Page size ......................2.2.3 Popup page ....................2.2.4 Transferring a project .................. - Page 4 2.10 Graphics files....................2.10.1 ax0.gif ......................2.10.2 num_bg.png....................2.10.3 mark1.png...................... 2.10.4 mark2.png...................... 2.10.5 hide3.png ....................... 2.10.6 hide4.png ....................... 2.10.7 Selection of marking ..................2.11 Javascript files....................2.12 HTML files...................... 2.13 Login masks ....................05.2012/V 1.2...
-
Page 5: Introduction
Introduction Introduction The RemoteVisu provides you with an operating interface for the HomeServer and FacilityServer that is optimally matched to the use of the visualisation on the Windows Media Center and Internet Explorer. Operation is carried out with the Media Center remote control. As an option, the Windows Media Center can be operated with an XBox 360 and the wireless XBox 360 wireless controller (see below). -
Page 6: General Information
As the software for the device purchased by you is being continuously further developed and updated, information in this manual may no longer be up-to-date. Current product information is always available on the Gira website: www.gira.com Current software updates and documentation for your product are also available. -
Page 7: Operating Devices
Area of application The RemoteVisu expands the existing HomeServer/FacilityServer visualisation functions. Any other use of the device and software is not permitted. Gira shall assume neither legal responsibility nor a warranty of any kind for errors and damage resulting from the improper use of the device and/or the related software. -
Page 8: Specifics
Introduction Specifics The RemoteVisu comprises the option of defining different sized visualisation pages. A visualisation page can be opened as a popup mask. No additional design is required for the RemoteVisu in a project. The layout is determined by the visualisation program. Installation The RemoteVisu is a component of the HomeServer/FacilityServer Expert software and is automatically installed with it. -
Page 9: Remotevisu
RemoteVisu RemoteVisu Sample project A sample project is included with the HomeServer/FacilityServer Expert software. The name of the sample project is: sample-yyyymmdd-rv.de Here "yyyymmdd" stands for the date of the respective file. 2.1.1 Scope of sample project Two resolutions can be selected in the sample project: 1680 x 1050 and 1024 x 768. -
Page 10: Start-Up
RemoteVisu Start-up 2.2.1 Setup Existing projects can be expanded with the HomeServer AjaxVisu without an additional design. Open the menu item Setup in the Expert. Create the following two symbols in the Project settings mask (see Image 2.1). The image ID is decisive for the definition. –... -
Page 11: Page Size
RemoteVisu 2.2.2 Page size If the area of a standard visualisation page is to be limited, this is possible with the XXPAGE symbol. If this symbol is set on a visualisation page, it defines the lower right-hand corner. All information which lies outside the limited area is not shown. Figure 2.2 Example of setting page size Create the symbol as described above:... -
Page 12: Popup Page
RemoteVisu 2.2.3 Popup page The RemoteVisu offers popup visualisation pages. If a visualisation page is to be laid over the visualisation page to be called (popup), it is possible with the XXPOPUP symbol. If this symbol is set on a visualisation page, it defines the lower right-hand corner and at the same time it defines this page as a popup. -
Page 13: Starting Visualisation
RemoteVisu Starting visualisation The RemoteVisu is started by calling one of the following pages in the Internet Explorer: – http://IP_DES_HS-FS/opt/hsrv-gira_en/startgast.htm – http://IP_DES_HS-FS/opt/hsrv-gira_en/start2.htm The two variants differ from each other in the user and the resolution used. 2.3.1 Start files startguest.htm starts the project with the user 'u1024' and the resolution 1024x768. start2.htm starts the project with the user 'u1680' and the resolution 1680x1050. - Page 14 RemoteVisu <div id="xmark" style="position:absolute; top:0px; left:0px; visibility:hidden;"> <img id="xmarkimg" src="img/hide.png" style="position:absolute; top:0px; left:0px;" /> <img id="xmarkimg2" src="img/mark2.png" style="visibility:hidden; position:absolute;top:0px;left:0px;" /> </div> <!-- Reconnect --> <div id="xreconnect" style="position:absolute; top:0px; left:0px; width:1024px; height:768px; overflow:hidden; text-align:center; visibility:hidden; background-color:red;"> Restore connection..<br/> <span id="tryCnt">*</span><br/> <span id="tryState"> </span> </div>...
-
Page 15: Variants B1, B2 Parameters
RemoteVisu Explanations The explanations refer to the setting options in this file. It is assumed that the standard HTML commands are known. Line Explanation Page heading or tab heading in the browser. 6 to 11 CSS settings for Login and Reconnect masks. Background settings. -
Page 16: Media Center
Install_RemoteVisu.cmd file and register the RemoteVisu in your Media Center with it. Then the HS/FS appears in the menu item Programs. <application title="My HS" id="{8F32B3C9-645B-45f6-BA93-9D20ACB476BA}" CompanyName="Gira, Giersiepen GmbH + Co KG" sharedviewport="true"> <entrypoint id="{E186AD7C-F9B8-45a3-9CA9-BE4C9C50AA08}" url="http://192.168.0.11/opt/hsrv-gira_en/startguest.htm" title="HS/FS RemoteVisu" description="HS/FS Client for RemoteVisu"... -
Page 17: Install_Remotevisu
RemoteVisu If several HomeServer are to be integrated, the two IDs (coloured blue) must be changed with any desired unique code. With one device, the IDs can remain unchanged. 2.4.2 Install_RemoteVisu The file Install_RemoteVisu.cmd: %windir%\ehome\RegisterMCEApp.exe /allusers RemoteVisu.mcl pause This installs a menu item in the Media Center. 2.4.3 Uninstall_RemoteVisu The file Uninstall_RemoteVisu.cmd:... - Page 18 RemoteVisu Mask Function Button Joystick Date + Time 0...9 0...9 Up/Down Navigation Left/Right Left/Right Save Back/OK Back/OK Cancel C/Cancel Mask Function Button Joystick Buddy Page + Down Down Page - Latest entry Left Left Oldest entry Right Right Close Back/C Back/C Mask Function...
- Page 19 RemoteVisu Mask Function Button Joystick Universal time Event + Down clock (UTC) Start page Event - Down Down Edit event TCL On/Off Skip Skip New event Right Right Close Back/C Back/C Mask Function Button Joystick Universal time Change date clock (UTC) Change date type <>...
-
Page 20: Safety
RemoteVisu Mask Function Button Joystick Universal time 0...9 0...9 Up/Down clock (UTC) Navigation Left/Right Left/Right Period Save Back Back Mask Function Button Joystick Universal time 0...9 0...9 Up/Down clock (UTC) Navigation Left/Right Left/Right Time*** Save Back Back Safety As with the B variants the login data are saved unencrypted, we only recommend using this variant for users, who only have an internal access authorisation. -
Page 21: Login Variants
RemoteVisu Login variants There are three variants for logging in: – Login via login mask – Data incl. password in HTML start page – Data without password in HTML start page URL for login: http://IP_DES_HS-FS/opt/hsrv-gira_en/[start page] Login type Displayed start page Enter user data Enter password for login... -
Page 22: Login Behaviour
RemoteVisu 2.7.4 Login behaviour The 5th parameter in startguest.htm, start2.htm. This parameter defines which visualisation page the user lands on following the login. There is no input field for this parameter on the Login mask. It must be changed directly in the startguest.htm or start2.htm. -
Page 23: Refresh Time
RemoteVisu 2.8.4 Refresh time Input field, in example R1. Abbreviation. If a change is caused with an element in the visualisation, for example a light is switched on, an automatic refresh of the page (the status of the object concerned is determined and shown on the visualisation) is carried out at intervals that double each time. -
Page 24: Installed Files
RemoteVisu Installed files The details of the RemoteVisu are described in the following. These files can be adapted to the user's own needs (colours etc.) with a minimal knowledge of HTML. The installed files are divided into several sections, each of which can be found in a separate subdirectory. - Page 25 RemoteVisu 2.10.3 mark1.png Only partially transparent, red-coloured area, i.e. it is not completely transparent. This area is used to mark the active element currently selected during navigation. 2.10.4 mark2.png An area only partially transparent, provided with a small symbol. Alternative to mark1.png. This area is used to mark the active element currently selected during navigation.
- Page 26 RemoteVisu 2.11 Javascript files The Javascript files are stored in the js subdirectory of the hsrv-gira_en folder. The files are used to breathe life into the HTML files, as it were. These files contain the program code which, for example, turns a drawn button or the transparent area which lies over it into a button that actually reacts to clicking.
- Page 28 Gira Giersiepen GmbH & Co. KG Electrical installation systems Industriegebiet Mermbach Dahlienstraße 42477 Radevormwald P.O. Box 12 20 42461 Radevormwald Germany Phone +49 (0) 2195 - 602-0 +49 (0) 2195 - 602-339 www.gira.com info@gira.com...
