Empulse R20
Attachment
with Etac Cross 5/6
EN
Etac
Cross 5
Etac
Cross 6
Etac
Cross 5
Etac
Cross 6
20°-45°
20°-45°
0
-5cm
+15cm
REAR
R20 Attachment - the docking pin should always be positioned as close as possible to
Required angle:
Required position: -5 cm to +15 cm
Horizontal adjustment
R20 Docking
pin (5Nm)
R20 Torque
Adapter Etac
block (5Nm)
Frame
20° - 45°
FRONT
Axle Sleeve
R20 attachment not
possible
Optimal position for
R20 attachment
Good position for
R20 attachment
Acceptable position
for R20 attachment
the cross brace
P/N: 000690732 Rev. B
