General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... Tape Measure
... Hammer or Rubber Mallet
... PVC, Super, or Crazy Glue
with #2 phillips bit
(recommended)
Oxford Trellis
11175
Model#
Part #
1
2" sq. x 65" Corner Post
2
2" sq. x 59½" Left Post
3
2" sq. x 59½" Right Post
4
⅞ x 1½ x 20" Top/Bottom Cross Rail
5
⅞ x 1½ x 19" Bent Top
6
¼ x 1½ x 49" Vertical Slat
7
¼ x 1½ x 19¼" Horizontal Slat
8
2" sq. x 14" Vinyl Ground Anchor
9
Hardware Bag
2" sq. Post Cap
¾" Painted Screw
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
1
1
1
4
2
4
12
3
1
3
8
1
