General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... PVC, Super, or Crazy Glue
... Hammer or Rubber Mallet
with #2 phillips bit
(recommended)
Elmwood Trellis
11190 (M)
Model#
Part #
1
2" sq. x 74" Left Post
2
2" sq. x 74" Right Post
3
⅞ x 1½ x 22" Top/Bottom Cross Rail
4
¼ x 1½ x 22" Horizontal Slat
5
¼ x 1½ x 66" Vertical Slat
6
2 x 2 x 16" Ground Anchors
7
Hardware Bag
2" sq." Post Cap
1¼" Painted Screw
1" Painted Self Tapping Screw
(for ground anchors)
115 Vision Parkway
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
1
1
2
7
2
2
1
2
4
4
1
Advertisement
Related Manuals for DuraTrel Elmwood Trellis 11190
Summary of Contents for DuraTrel Elmwood Trellis 11190
- Page 1 Elmwood Trellis 11190 (M) Assembly Instructions Model# Part # Description 2" sq. x 74" Left Post 2" sq. x 74" Right Post ⅞ x 1½ x 22" Top/Bottom Cross Rail ¼ x 1½ x 22" Horizontal Slat ¼ x 1½ x 66" Vertical Slat 2 x 2 x 16"...
- Page 2 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
- Page 3 Lay out one 74" left post (part 1). Starting at bottom, insert one 22" top/bottom cross rail (part 3) and seven 22" horizontal slat (part 4). Insert free ends of bottom cross rail and horizontal slats into 74" right post (part 2). Weave one 66"...
- Page 4 Figure 2 Figure 1 Trellis Arbor Option 1 (soft ground) Slide one 16 inch ground anchor into bottom of each post. Slide ground anchor up to bottom cross rail. Using two 1 inch self-tapping screws per post, screw the post to the ground anchor (figure 1). When fastening, use one screw on each opposite side as shown in the drawing.
