General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... Tape Measure
... Hammer or Rubber Mallet
with #2 phillips bit
(recommended)
Wishing Well
11133
Model#
Part #
1
4" sq. x 64" Single Hole Post
2
4" sq. x 64" Double Hole Post
3
4" sq. x 32" Base Post
4
1½ x 4 x 18" Base Cross Rail
5
⅞ x 3 x 24½" Base Rail
6
1½ x 5½ x 43" Roof Rail
7
1½ x 5½ x 43" Angled Roof Rail
8
1½ x 5½ x 29½" Roof Truss
9
1½ x 5½ x 7" Peak Block
10
18¾" Roof Bracket
11
¾ x 39" Rod
12
¾ x 5" Handle Rod
13
⅞ x 1½ x 10" Handle
14
22" Roof End Cap
15
4" sq. Flat Post Cap
16
⅞ x 1½ x 16" Ground Anchor
17
Hardware Bag
⅞ x 1½" End Cap
2" Painted Screw
1¼" Painted Screw
¾" Painted Screw
Super Glue Tube
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
1
1
4
12
24
6
2
2
2
4
1
1
1
4
6
4
1
2
28
11
104
1
1
