Wall mount showerhead

Advertisement

SERVICE PARTS
72830T-L
1082904
1082902
77420
1242635
870992
1225787
1154399
1225788
1225727**
1225773
1225772
1225774
1225775
1225780
**Color code must be specified when ordering.
1227406-2A-E
Wall Mount Showerhead
1225747**
1225772
1225771
1225773
1262748
1227384
1227373
1227376
BEITOU
Installation INSTRUCTIONS

BEFORE YOU BEGIN

All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.

NOTES:

1. Flush the water supply pipes thoroughly to remove debris.
2. Recommended working pressures: 2~5bar.
3. The highest working pressure for showerhead is 0.5MPa(5 bar). If it exceeds 0.5MPa(5 bar), a pressure
reducer is needed. The highest water and environment temperature is 60°C. Please keep shower head away
from heater, or it may become damaged and cause injury to the user.
4. Please ensure only apply water pressure test on the product, and empty the air in pipe and faucet thoroughly
before the test. Please ensure test pressure below 0.8MPa(8bar) and test duration within 30 minutes.
5. If water pressure is too high, water flow is excess, please install the attached flow regulator.

ROUGH-IN DIMENSIONS

1262747
1225742
1275652
1225743
1227385
1225755**
1225718
4
1227406-2A-E
72830T-L
Wall Mount Showerhead
3-G1/2-B
550
14
31~41
Finished Wall
Finished Floor
BEITOU
72830T-L
1
