- Page 1 Alle Height- adjustable Desk Assembly Instruction...
- Page 2 Alle Height-adjustable Desk Subtle detailing The solid-wood Alle Tables by Staffan Holm are a family of furniture that is especially Hem: traditional modes of making reclaimed for modern manufacture; good looks and practicality given equal consideration; engineering and hand- work combined; quality materials used liberally.
- Page 3 Read this before assembly The Alle Height-adjustable desk is an electronical height-adjustable table consisting of one metal frame, one solid wood tabletop and one metal cable management tray. The metal frame is a partly completed machinery produced by LINAK. Read their user manual before installing this table.
- Page 4 Important information Important information on products can be found under the following headings: ! Failure to comply with these instructions may result in accidents involving serious personal injury. Failing to follow these instructions can result in the product being damaged or being destroyed.
- Page 5 Before installation, re-installation, cleaning, or troubleshooting • Stop the frame. • Switch off the power supply and pull out the mains plug. • Relieve the frame of any loads, which may be released during the work. • Review the assembly instructions to confirm that the appropriate critical components and accessories are being used with this product.
- Page 6 Repairs In order to avoid the risk of malfunction, all DESKLINER repairs must only be carried out by authorised LINAK workshops or repairers, as special tools must be used and special gaskets must be fitted. Lifting units under warranty must also be returned to authorised LINAK workshops.
- Page 7 Parts 20 x M4,5x20 5 x M4,5x18 3 x M6x20 2 x M4x35 for cable clips for cable tray for beam for controller 8 x M6x15 5 x cable clip for foot beam 2x cable tie 1 x power cable 1 ×...
- Page 8 Step 1 Please extend the beam to the appropriate length for the table top. Match it to the pre-drilled holes in the table top. The beam components must not be separated in order to keep the drive shaft connected. Ensure that the RJ45 and power sockets remain accessible through hole in casing.
- Page 9 Step 3 Place the assembled frame upside down onto the pre-drilled holes in the table top. Double check that the power and RJ45 sockets are accesible. Top view Step 4 Fasten the DF2 Frame to the table top, by using 20 mounting screws: 4 screws into each cantilever on both sides of the table, 4 screws...
- Page 10 Step 5 Mount the legs to the frame. Please ensure that the columns are fully retracted before mounting. 1. Tilt and position the leg into place by using the guide notches. 2. Pivot the leg down until both fins ‘click’ into place. Repeat this for the second leg.
- Page 11 Step 6 Attach the control panel. First, plug the control panel cable into the RJ45 socket. Then, attach the anti collision desk sensor. Attach the control panel to the desk top with 2 of the M4x35mm screws into the pre-drilled holes. Optional: Screw 2 cable clips into the pre-drilled holes in the table...
- Page 12 Step 7 Plug the power cord into the beam and use the cable clip to hold the excess cable. Please note: If you are assembling multiple tables, ensure only one control panel is connected to the beam at one time. Do not plug the power cord to an electrical outlet yet!
- Page 13 Step 8 Use the cable ties to wind up the cables if needed. Optional: Use the cable ties to wind up the cables if needed. Screw 3 cable clips into the pre-drilled holes in the table top. Thread the power cable through the 3 cable clips, guiding the cable to the cable tray.
- Page 14 Step 9 Attach the cable tray by using 3 of the M6x20 screws.
- Page 15 Step 11 With the help of another person, flip the table over onto its legs. Then plug the power cable into a power outlet. Your Alle Height-adjustable Desk is now ready assembled!
- Page 16 Should you have any problems assembling your product, contact us at info@hem.com. We’re always happy to help! We have carefully selected the materials used in this product, and ask you to treat it responsibly too. Please recycle all packaging according to your local disposal rules.
