Ez-Fet Debug Probe; Energytrace Technology - Texas Instruments LaunchPad MSP‑EXP430G2ET User Manual

Hardware
The MSP-EXP430G2ET LaunchPad development kit features EnergyTrace technology but does not have
support for EnergyTrace++ technology (see
across the MSP430 portfolio.
Features
Current monitoring
CPU state
Peripheral and system states
Devices supported
Development tool required
The dotted line through J101 shown in
signals that cross this line can be disconnected by jumpers on J101, the isolation jumper block. For details
on the isolation jumper block, see
The eZ-FET also provides a backchannel UART-over-USB connection with the host, which can be very
useful during debugging and for easy communication with a PC. For details on the backchannel
connection, see Section
For more information about the eZ-FET hardware, see the schematics in
Design Files. For more information about the software and the debugger, see the
2.2.3 Debug Probe Connection: Isolation Jumper Block
The isolation jumper block at jumper J101 allows the user to connect or disconnect signals that cross from
the eZ-FET domain into the MSP430G2553 target domain. This includes eZ-FET Spy-Bi-Wire signals,
application UART signals, and 3.3-V and 5-V power.
Reasons to open these connections:
• To remove any and all influence from the eZ-FET debug probe for high-accuracy target power
measurements
8 MSP430G2553 LaunchPad™ Development Kit (MSP ‑ EXP430G2ET)
Figure 5. eZ-FET Debug Probe
Table
Table 1. EnergyTrace Technology

EnergyTrace Technology

✓
All MSP430 MCUs
MSP-FET or eZ-FET
Figure 5 divides the eZ-FET debug probe from the target area. The
Section 2.2.3.
2.2.4.
Copyright © 2018–2020, Texas Instruments Incorporated
1). The EnergyTrace technology functionality varies
EnergyTrace++ Technology
MSP430FR59xx and MSP430FR69xx MCUs
Section 6
SLAU772A – June 2018 – Revised March 2020
www.ti.com
✓
✓
✓
MSP-FET or eZ-FET
and the Hardware
eZ-FET wiki.
