- Page 1 Your new Rose spinning wheel majacraft all you need to spin your dreams... majacraft...
- Page 2 Thank you for choosing Majacraft, it is your belief in us that drive our innovation and creativity in building captivating tools for you.
- Page 3 Assembling a Majacraft Rose These instructions demonstrate how to assemble your Majacraft Rose spinning wheel 1. Prepare the components We recommend that you find a clear work area where you can lay out all the components for working on them.
- Page 4 Insert the JCB bolts through the holes and into the stem assembly. Turn the base over and insert the JCB bolt in the hole underneath. Partially tighten the bolts, checking that they are threaded in correctly before finally tightening all bolts. majacraft...
- Page 5 The long side of each pedal goes nearest to the central base. We recommend you insert the two screws in the hinge holes closest to the outside edge of pedal. This keeps the still and aligned while you put in the remaining screws. majacraft...
-
Page 6: Drive Wheel
Take the spinning head and slide it down into the handle. Push the JCB bolt in a little way through the hole in the top of the handle. Align the wooden spacer tube in the handle so the bolt will can be pushed through the centre. majacraft... - Page 7 When you slide the pulley on the flyer shaft, it is important that the grub screw is lined up above the flat that has been ground on the flyer shaft. When the pulley is correctly aligned, use the allen key to tighten the grub screw. majacraft...
- Page 8 3 - Silver 32mm (1 1/4”) screws (in the hardware bag) Posidrive screwdriver The drive wheel has been predrilled with the holes for the aluminium crank assembly. You will need a posi-drive screwdriver and the three 32mm silver screws. Make sure the drive belt is on. majacraft...
- Page 9 When the rod end is aligned correctly, screw the 25mm screw back into place. The screw should only be tightened until the head just touches the side of the pedal. DO NOT OVERTIGHTEN! CORRECT INCORRECT majacraft...
- Page 10 Now slide the bobbin on. The brake band is recommended to be crossed. From the spring pin,the brake band should go up and over the top of the bobbin then round underneath and back up the the tension knob. majacraft...
- Page 11 While not essential, it will help keep your Rose looking excellent into the future. Your Majacraft Rose is now assembled and you are ready to start on a new spinning adventure! From the team at Majacraft, we wish you great spinning in the future.
- Page 12 Notes majacraft rose_assembly_1.08_16-11-2015...
