DTF-720AB User's Guide

Table of Contents

Safety Precautions ..................................................2
Component Functions ..............................................5
Adjusting the stand ............................................................................... 6
Installing DTF-720AB on a Mount Arm ................................................... 6
Accessory Check .....................................................7
Connecting DTF-720AB ..........................................8
Installing DTF-720AB Driver ....................................10
Windows Setup .................................................................................... 10
Mac OS X Setup ................................................................................... 11
Uninstalling the Tablet Driver ................................................................. 11
The DTF-720AB Display ...........................................12
The Auto-Adjust Function ....................................................................... 12
The DTF-720AB Power Saving Function .................................................. 12
On-Screen Display (OSD) Menu Buttons ................................................. 14
Using the OSD Menu ............................................................................ 14
Basic operation ......................................................17
How to use the Tablet Buttons ................................................................. 17
Using the Control Panel ...........................................18
Displaying the Control Panel .................................................................. 18
Control Panel Basics .............................................................................. 18
Supplementary Information ....................................23
Removing Stains ................................................................................... 23
Replacing the Pen Nib ........................................................................... 23
Troubleshooting ......................................................24
Display Troubleshooting ........................................................................ 24
General Troubleshooting ....................................................................... 25
Troubleshooting for Windows ................................................................ 25
Troubleshooting for Macintosh ............................................................... 26
Specifi cation ...........................................................26
Obtaining Technical Support .................................27
T F 7 2 0 A B ( E ) . i n d b 1
9 . 1 . 1 5
: 3 5 : 1 2 P M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTF-720AB and is the answer not in the manual?

Questions and answers

Related Manuals for Wacom DTF-720AB

Summary of Contents for Wacom DTF-720AB

  • Page 1: Table Of Contents

    DTF-720AB User's Guide Table of Contents Safety Precautions ..........2 Component Functions ..........5 Adjusting the stand ................6 Installing DTF-720AB on a Mount Arm ........... 6 Accessory Check .............7 Connecting DTF-720AB ..........8 Installing DTF-720AB Driver ........10 Windows Setup ..................10 Mac OS X Setup ................... 11 Uninstalling the Tablet Driver ..............

  • Page 2: Safety Precautions

    The following symbols appear throughout this user guide in order to ensure safe use of the DTF-720AB (hereafter referred to as “DTF-720AB,” “the product” or “this product”). Please read these items carefully and always heed the Warning and Caution items when using your DTF-720AB.
  • Page 3 Caution ■ ■ Do not use organic solvents to clean When not using this product for a long this product. period of time When cleaning the product, never use For safety reasons, when you will not be such organic solvents as alcohol. Such using the product for a considerable length solvents may cause discoloration and of time, disconnect the power adapter from...
  • Page 4 ●  O ther product names and related items are the trademarks or registered trademarks of each concerned company. Precautions 1 Wacom Company, Ltd. holds the copyright to the auxiliary tablet. 2 The unauthorized duplication or reproduction in whole or in part of the tablet driver or this user guide is expressly prohibited.

  • Page 5: Component Functions

    Pen Tether hole USB2.0Hub A USB 2.0 hub is available on both the left and right sides of the DTF-720AB.  5  T F 7 2 0 A B ( E ) . i n d b 5 9 . 1 . 1 5...

  • Page 6: Adjusting The Stand

      L ower the stand carefully. Installing DTF-720AB on a Mount Arm This product conforms to the Video Electronics Standard Association’s (VESA) Flat Panel Monitor Physical Mounting Interface Standard (FPMPMI).

  • Page 7: Accessory Check

    Accessory Check ● Pen ● Power Adapter ● User's Guide (This booklet) ● Power Cables EU type User's Guide AU type ● Tablet Driver CD-ROM ● Application CD-ROM TW type ● Analog RGB Cable ● Pen Tether ● Adapter Plug (UK type) ●...

  • Page 8: Connecting Dtf-720Ab

    Turn on your computer. While looking at the LCD screen, confi gure the color resolution and size settings. - Do not modify the refresh rate. Setting the rate to a value that exceeds the DTF-720AB refresh rate may result in loss of picture.
  • Page 9 Computer USB connector USB cable To USB port Connectors Area DC Power Input Terminal Outlet Power cable* DTF-720AB Rear View Power Adapter Computer Analog RGB connector （Input） Analog RGB cable Analog RGB connector （Output） To analog RGB port To monitor or projector * Please use the proper power cord or adapter plug for your region.  9  T F 7 2 0 A B ( E ) . i n d b 9 9 .

  • Page 10: Installing Dtf-720Ab Driver

    Please note that the driver for Windows 98 SE and Me are no longer included on the tablet driver CD-ROM. If you plan to use your DTF-720AB with a PC running Windows 98 SE or Me, please download the appropriate driver from http://www.wacom-asia.com/ download/download_index.html...

  • Page 11: Mac Os X Setup

    CD-ROM and double-click on Install or Install.app. After installing OS X, input your password. Click on Install Wacom Tablet and installation will begin. Thereafter, follow the screen instructions and continue the installation process. If during processing, the identity confi rmation dialog box displays, input your password *.

  • Page 12: The Dtf-720Ab Display

    When the Auto-Adjust function is operating, only the power switch is operational. Pen calibration may be necessary after adjusting screen position. ( → P13) The DTF-720AB Power Saving Function This product is in compliance with VESA and ENERGY STAR power-saving guidelines.

  • Page 13: Blurring And Protrusion Of The Picture From The Lcd Panel

    Blurring and Protrusion of the Picture from the LCD Panel This setting is effective when the product and computer are connected by a RGB cable. Depending on the type of computer and graphics board, the Auto-Adjust function is sometimes not able to operate at full power, resulting in the picture blurring and protruding from the LCD panel.

  • Page 14: On-Screen Display (Osd) Menu Buttons

    On-Screen Display (OSD) Menu Buttons ー ＋ MENU ENTER ： Menu button ENTER Button ­ , + ： buttons buttons Opens or closes the OSD Activates or deactivates the selected OSD You can select an option that can Menu. menu item. be activated.After activatng a selected option, press the + button to increase a selected item value,...
  • Page 15 Types of OSD Menus Contrast   Language Select to choose a Select to increase language option for or decrease image the OSD: English, contrast. Deutsch, Francais, Cannot be Espanol, Italiano, or adjusted if DIRECT Japanese. is selected in the Color menu. Brightness  ...
  • Page 16 Phase Horizontal Center   Select to reduce or Select to move the eliminate horizontal screen image left or distortion lines. right. To automatically To automatically adjust, use the Reset adjust, use the Reset menu. menu. Pitch Vertical Center   Select to reduce or Select to move the eliminate vertical screen image up or...

  • Page 17: Basic Operation

    Basic operation How to use the Tablet Buttons The tablet buttons increase your work efficiency by making navigating through documents and websites quick and simple. The tablet buttons can be used in Windows-based PCs. To use the tablet buttons, install the button driver to your PC.

  • Page 18: Using The Control Panel

    Using the Control Panel Change the settings for the pen and adjust the pointer and pen tip positions with the control panel. *When connecting and using multiple tablets, see page 22. Displaying the Control Panel Opening the Control Panel in Windows Click on the Windows Start button, go to All Programs (P) or Programs (P), open Tablet and select Pen Tablet Opening the Control Panel in Macintosh...
  • Page 19 Switch and Button Settings Function Names Description Click Performs the same operations as a normal mouse. Right Click Middle Click Simulates a 4th mouse button click, which on Windows systems typically 4th click(Back) issues the Back command in browser applications. Not available on Macintosh systems.
  • Page 20 Function Names Description Journal This function opens Microsoft Journal, an application for Windows Vista and tablet PC. Open/Run Opens an application or fi le. This function will open a dialog box. Click Browse to select an application or file. The selection you make appears in the Application To Run box. Click "OK"...

  • Page 21: Synchronizing The Positions Of The Pen Tip And Pointer

      Synchronizing the Positions of the Pen Tip and Pointer Make the necessary adjustments so that when the pen nib is brought near the LCD screen, the pointer displays properly in the area where the pen nib is placed. *Please refer to pages 12 and 13 to make screen image adjustments. *Please refer to page 22 when using multiple Interactive Pen Displays.

  • Page 22: Using Multiple Interactive Pen Displays

      Using Multiple Interactive Pen Displays When multiple Interactive Pen Displays are connected and are to be used, it is necessary to set up the pen and calibrate for each Interactive Pen Displays individually. Please follow the procedures below to carry this out. Bring the pen tip near the display for which the setup is to take place.

  • Page 23: Supplementary Information

    Supplementary Information Removing Stains If the product casing or pen becomes soiled, wipe off with a clean, soft cloth. If this fails to remove the stains, soak a clean, soft cloth with a water-diluted detergent mixture, wring thoroughly and wipe off. If the protective covering for the LCD display becomes soiled, wipe with a dry, soft cloth.

  • Page 24: Troubleshooting

    Troubleshooting Display Troubleshooting If One of These Messages Should Appear... Message What to Do Prior to connecting the product, if you have a monitor that you have been using, connect it and then adjust the horizontal frequency to 30–80 kHz and the vertical frequency to 50 –75 Hz.

  • Page 25: Pen Troubleshooting (For Both Windows And Macintosh)

    What to Do When a replacement computer Installing the newest version of tablet driver may resolve this problem. The is purchased or new software newest tablet driver can be downloaded from the Wacom homepage. is used, the tablet cannot be www.wacom-asia.com used.

  • Page 26: Troubleshooting For Macintosh

    Troubleshooting for Macintosh Condition What to Do -Check the connection of the USB connector. Connect directly to the computer’s USB port. E v e n w h e n c o n n e c t e d t o -If equipped with a USB card, the system software has probably not been t h e U S B p o r t , t h e p e n i s installed properly.

  • Page 27: Obtaining Technical Support

    (proof of purchase) or if issued, the warranty card from your local reseller or distributor. Wacom's Limited Warranty Policy for Asia Pacifi c can be found on the Asia Pacifi c website at: www.wacom-asia.com/technical/warranty...
  • Page 28 FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
