- Page 1 BLK BOX ROPE STORAGE HOOK 21-0181 PRODUCT SPECIFICATION OWNERS MANUAL & QUICK START GUIDE PRODUCT WEIGHT NOTE : PLEASE READ ALL THE INSTRUCTIONS DIMENSIONS CAREFULLY BEFORE ASSEMBLING THIS PRODUCT. 264mm x 150mm x 150mm #MADEINBELFAST...
- Page 2 WARNING SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE). WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
- Page 3 INSTALLATION MEASURE, MARK AND DRILL HOLES USING GUIDES PROVIDED. 90mm 1640mm CENTER LINE SLEEVE ANCHOR BOLT FITTING -DRILL 10MM HOLE INTO THE WALL, 90MM DEEP -VACUUM OUT THE DUST. DRILL HOLE VACUUM 90MM #MADEINBELFAST...
- Page 4 ATTACH ROPE STORAGE HOOK (21-0249) TO THE WALL USING SLEEVE ANCHORS (10-0031) AND WASHERS (10-0019) AS SHOWN. TIGHTEN ALL SLEEVE ANCHORS TO SPECIFIED TORQUE. SLEEVE ANCHOR BOLT FITTING -HAMMER SLEEVE ANCHOR INTO THE HOLE. -TIGHTEN SLEEVE ANCHOR TO SPECIFIED TORQUE HAMMER IN TIGHTEN BOLT...
- Page 5 1:1 SCALE FASTENERS M10x80 SLEEVE ANCHOR 10-0031 M10 FLAT WASHER 10-0019 FOR TERMS AND CONDITIONS VISIT OUR WEBSITE AT www.blkboxfitness.com/pages/terms-conditions GET IN TOUCH TEL: 028 9045 4123 EMAIL: info@blkboxfitness.com DISCOVER MORE AT: www.blkboxfitness.com #MADEINBELFAST...
