Item#1682A: ARM CHAIR
A
Chair Back
1pc
Right Side Facing Arm
E
1pc
Bolt
I
3pcs
ASSEMBLY INSTRUCTION
B
Seat Cushion- Frame
1pc
F
Screw
2pcs
J
Flat washer
11 pcs
C
Front Leg
2pcs
Bolt
G
4pcs
Spring washer
K
11 pcs
This page lists all the contents included
in the box. Please take time to identify
the hardware as well as the individual
components to this product. As you
unpack and prepare for assembly, place
the contents on a carpeted or padded
area to protect them from damage.
For items use on wooden floor,
hard surfaces or carpets, it is
recommended to install protective pads
under all legs and supports to
avoid/prevent from damages/scratches
and discoloration.
D
Left Side Facing Arm
1pc
Bolt
H
4pcs
L
(12mm)
1pc
Made in Vietnam
Advertisement
Table of Contents
Related Manuals for Homelegance 1682A
Summary of Contents for Homelegance 1682A
- Page 1 ASSEMBLY INSTRUCTION Item#1682A: ARM CHAIR Seat Cushion- Frame Chair Back Front Leg Left Side Facing Arm 2pcs Bolt Bolt Right Side Facing Arm Screw 4pcs 4pcs 2pcs Bolt Flat washer Spring washer (12mm) 11 pcs 3pcs 11 pcs This page lists all the contents included in the box.
- Page 2 Attach the seat cushion frame (B) to the chair back (A) with 1pc bolt (I), 1pc flat washer(J), 1 pc spring washer (K) then tighten using wrench (L). Attach the seat cushion frame (B) to the chair back (A) with 4pcs bolt (G), 4pcs flat washer(J), 4 pcs spring washer (K) then tighten using wrench (L).
- Page 3 Attach the front legs (C) to the seat cushion frame (B) with 4pcs bolt (H), 4 pcs flat washer (J), 4 pcs spring washer (K) then tighten using wrench (L). 4pcs 4pcs 4pcs Attach the left side facing arm (D) and right side facing arm (E) to the chair back (A) and seat cushion frame (B) with 2pcs bolt (I), 2pcs flat washer (J), 2pcs spring washer (K) then tighten using wrench (L), after use screw (F) provided as shown.
