1.2.1
Features
•
Intelligent WiMAX subscriber unit for wireless triple-play service delivery
Outdoor unit with ETH interface to indoor unit
•
Automatic, self-configured, plug-n-play
•
Supporting 1.X, 2.X and 3.X GHz bands
•
1.3
Package Components and Unpacking
Check that the package contains:
1.
WiN52xx ODU with integrated flat antenna
2.
Pole/wall mounting hardware
In case of damage, contact the shipping company.
1.4
Safety Information
RF Exposure
The WiN5200, an outdoor CPE, is compliant with the requirements set forth in CFR 47 section
1.1307, addressing RF Exposure from radio frequency devices as defined in OET Bulletin 65.
The outdoor CPE mobile unit should be positioned more than 0.6 feet (20 cm) from humans.
The outdoor CPE fixed unit should be positioned at least 7 feet (2m) from humans.
Lightning Protection
When WiN5200 is installed in an outdoor location, all indoor components (Ethernet, power
supply) should be connected through a lightning protector.
The purpose of the lightning protection is to protect people and equipment located indoors
from lightning that might strike the WiN5200 or its outdoor cables. Therefore, the lightning
protector device should be installed indoors, as close as possible to the point where the cables
enter the building. The lightning protector can also be installed outdoors, as long as the cables
that lead from it indoors are well protected from lightning between the box and the building
entrance.
Power Cord Protection
The WiN5200 should always be connected to the WiN1010 data adapter for both power
supply and data transfer purposes.
WiN5200
Introduction | 8
