4.1
Safety Hazards
Warning
Installing the WiN5200 can pose a serious hazard. Be sure to take precautions to avoid the
following:
Exposure to high voltage lines during installation
Falls when working at heights or with ladders
Injuries from dropping tools
Contact with AC wiring
4.2
Tools and Cables Required for the Installation
WiN5200 Ethernet ODU CPE Requirements:
IDU-to-ODU Cat5e Ethernet cable (100m MAX) and two RJ-45 plug connectors
Note
The Cat5e Ethernet cable is not included. Please refer to "Appendix B – IDU to ODU cable specification"
for detailed technical specifications.
RJ-45 connectors crimping tool
Ground cable with an appropriate termination
General Installation Tools:
Flat Screwdriver
Wrench
Driller
Hammer
Adjustable Ratcheting Socket Wrench
4.3
Installing the WiN5200
The installation involves the WiN5200 and the mounting bracket. The mounting bracket
should be installed at the first instance and the WiN5200 should be inserted into it, as detailed
in the following instructions.
WiN5200
Installation Procedure | 31
