PRODUCT NO.
BASE MODEL NO.
FRT21FG4CQ0
FRT21FG4C
FRT21FG4CW0
FRT21FG4C
MARKET
North America
WIRING DIAGRAM - # 240379010
OWNER'S GUIDE - # 240400109
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995389128
030416
-EN/SERVICE /ECL
357
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21FG4C
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21FG4C
Summary of Contents for Frigidaire FRT21FG4C
- Page 1 PRODUCT NO. BASE MODEL NO. FRT21FG4CQ0 FRT21FG4C FRT21FG4CW0 FRT21FG4C MARKET North America WIRING DIAGRAM - # 240379010 OWNER’S GUIDE - # 240400109 SERVICE DATA SHEET - # 240379010 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR...
- Page 2 Publication No. FRT21FG4C 5995389128 DOOR 04/03...
- Page 3 A = FRT21FG4C (FRT21FG4CW0) B = FRT21FG4C (FRT21FG4CQ0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT21FG4C DOOR PART NO DESCRIPTION 240514607 Gasket,seal ,white ,frzr door ,magnetic 240514608 Gasket,seal ,white ,refr door ,magnetic 240534901 Rack-door 240534701 Rack-door,4B 240337701...
- Page 4 Publication No. FRT21FG4C 5995389128 CABINET 04/03...
- Page 5 A = FRT21FG4C (FRT21FG4CW0) B = FRT21FG4C (FRT21FG4CQ0) POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21FG4C CABINET PART NO DESCRIPTION 240355402 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan...
- Page 6 Publication No. FRT21FG4C 5995389128 SHELVES 04/03...
- Page 7 A = FRT21FG4C (FRT21FG4CW0) B = FRT21FG4C (FRT21FG4CQ0) POS. NO 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21FG4C SHELVES PART NO DESCRIPTION 240358003 Shelf,freezer ,full-width ,wire 5303299664 Spacer,shelf 240545901 Diffuser-air,top 240362601 Diffuser,air ,bottom 240505801...
- Page 8 Publication No. FRT21FG4C 5995389128 SYSTEM 04/03...
- Page 9 A = FRT21FG4C (FRT21FG4CW0) B = FRT21FG4C (FRT21FG4CQ0) POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21FG4C SYSTEM...
-
Page 10: Ice Maker
Publication No. FRT21FG4C 5995389128 ICE MAKER 04/03... - Page 11 A = FRT21FG4C (FRT21FG4CW0) B = FRT21FG4C (FRT21FG4CQ0) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21FG4C ICE MAKER PART NO DESCRIPTION 218976901 Tube-water inlet,inlet valve ,to ice maker...
-
Page 12: Wiring Schematic
Publication No. FRT21FG4C 5995389128 WIRING SCHEMATIC 04/03... -
Page 13: Wiring Diagram
FRT21FG4C Publication No. 5995389128 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
