2.2 Mechanical Environmental Performance
Serial No. Experiment Items
1 Impact
2 Vibration
3 Crash
4 Drop
For more information, please visit our website:
Test methods
a. Test equipment and method apply to GB/T 2423.5—2008
b. Normal installation and without power supply, the peak
acceleration is 490 m/s² and pulse duration is 11 ms. Six sides
do these steps 3 times.
a. Test equipment and method apply to GB/T 2423.10—2008
b. Normal installation and without power supply, the vibration
frequency is 5 Hz ~ 300 Hz and scanning speed is 1 otc/min.
In 5 Hz ~ 11 Hz frequency range, the amplitude is 10 mm. In
11 Hz ~ 300 Hz frequency range, the vibration acceleration is
50 m/s². On X, Y, Z three mutually perpendicular axis, each
axial does it for 8 hours.
a. Test equipment and method apply to GB/T 2423.6—1995
b. Without power supply and any external protections, Peak
acceleration is 150 m/s², rated pulse duration is 6 ms. Per
direction collision is100±5 times
a. Test equipment and methods apply to GB/T 2423.8—1995
b. Without power supply and any external protections, it falls
from 500 mm height
