1.3.6 Interface
To ensure the waterproof, the external interface of
from XMRCP4, and then the joint distributes according to their functions, details are as following:
Definition：
Connector Name
MDVR
CAM
MIC
SENSOR
For more information, please visit our website:
Function
Black 10PIN aviation-din male connector
connects to Streamax MDVR.
Yellow 4PIN aviation-din
connects to reversing camera.
Connects to driver microphone.
Yellow hanging line, reversing signal
detection port, high level effective. For
reversing control.
www. syscom.mx
XMRCP4 uses harness, which leads a bunch of buses
Definition
connector
