Team C TS2 Manual page 15

24
Rear Suspension
T02013 3.1x6x1 Plastic Washer
...........................4
25
Rear Suspension
x2 1:1
Projection.Note direction
approx.53mm
T02029
TG2024
T02029 4.8mm Ball End-Long
............4
TG2024 3x72 Turnbuckle
............2
Assemble Both Left And Right
L
R
All manuals and user guides at all-guides.com
T02057 3x30.5 Hinge pin Rear outer
............2
T02029
T02093
T02057 2.3 E-ring
............4
11
T02013
T02057 3x30.5
T02057 2.3
L
R
T02093
Ball stud sponge
