PRODUCT NO.
BASE MODEL NO.
FRT18NP7AW0
FRT18NP7A
MARKET
North America
WIRING DIAGRAM - #240398801
OWNER'S GUIDE - #240400105
SERVICE DATA SHEET - #240379007
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
white
Publication No.
5995359733
011013
-EN/SERVICE/KHB
390
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18NP7A
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18NP7A
Summary of Contents for Frigidaire FRT18NP7A
- Page 1 PRODUCT NO. BASE MODEL NO. FRT18NP7AW0 FRT18NP7A MARKET North America WIRING DIAGRAM - #240398801 OWNER’S GUIDE - #240400105 SERVICE DATA SHEET - #240379007 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a white TOP MOUNT...
- Page 2 Publication No. FRT18NP7AW0 5995359733 DOOR 10/01...
- Page 3 POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRT18NP7AW0 DOOR PART NO DESCRIPTION 240514605 Gasket-frzr door,white ,magnetic 240514606 Gasket-refr door,white ,magnetic 240311502 Support-door rack,2 liter ,RH 240311501 Support-door rack,2 liter ,LH 240338303 Door-dairy 240331402 Rack-door,17.99" x 1.72" 240381301 Plug-button,hinge brg hole ,white ,(2) 240461601...
- Page 4 Publication No. FRT18NP7AW0 5995359733 CABINET 10/01...
- Page 5 POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18NP7AW0 CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462005 Cover-evap coil 240371302 Seal-coil cover...
- Page 6 Publication No. FRT18NP7AW0 5995359733 SHELVES 10/01...
- Page 7 POS. NO 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18NP7AW0 SHELVES PART NO DESCRIPTION 215667501 Tray-ice,plastic 240358002 Shelf-freezer,full width 5303299664 Spacer-shelf 240362502 Diffuser-air,top 240362601 Diffuser-air,bottom 240392601 Seal-diffuser 240505801 Switch-light/lamp 240436701 Light Bulb/Lamp, A-15, 40 W, 120 V, miniature 241500701 Socket-light/lamp 240352701...
- Page 8 Publication No. FRT18NP7AW0 5995359733 SYSTEM 10/01...
- Page 9 POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18NP7AW0 SYSTEM PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Harness-wiring,machine compt 240385401 Wiring Harness,freezer section 240388701...
-
Page 10: Wiring Schematic
Publication No. FRT18NP7AW0 5995359733 WIRING SCHEMATIC 10/01... -
Page 11: Wiring Diagram
FRT18NP7AW0 Publication No. 5995359733 WIRING DIAGRAM # = Fast-moving Parts 10/01 * = Non-Illustrated Parts...
