PRODUCT NO.
BASE MODEL NO.
FRT18KS6CQ0
FRT18KS6C
FRT18KS6CW0
FRT18KS6C
MARKET
North America
WIRING DIAGRAM - # 240379010
OWNER'S GUIDE - # 240400109
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995389052
030415
-EN/SERVICE /ECL
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18KS6C
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT18KS6C
Summary of Contents for Frigidaire FRT18KS6C
- Page 1 PRODUCT NO. BASE MODEL NO. FRT18KS6CQ0 FRT18KS6C FRT18KS6CW0 FRT18KS6C MARKET North America WIRING DIAGRAM - # 240379010 OWNER’S GUIDE - # 240400109 SERVICE DATA SHEET - # 240379010 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR...
- Page 2 Publication No. FRT18KS6C 5995389052 DOOR 04/03...
- Page 3 A = FRT18KS6C (FRT18KS6CW0) B = FRT18KS6C (FRT18KS6CQ0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT18KS6C DOOR PART NO DESCRIPTION 240542103 Gasket-frzr door,white ,magnetic 240542106 Gasket-refr door,white ,magnetic 240337703 Door-dairy,w/o graphics ,clear 240381301 Plug-button,white ,hinge brg hole ,(2)
- Page 4 Publication No. FRT18KS6C 5995389052 CABINET 03/02...
- Page 5 A = FRT18KS6C (FRT18KS6CW0) B = FRT18KS6C (FRT18KS6CQ0) POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18KS6C CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan...
- Page 6 Publication No. FRT18KS6C 5995389052 SHELVES 04/03...
- Page 7 A = FRT18KS6C (FRT18KS6CW0) B = FRT18KS6C (FRT18KS6CQ0) POS. NO 14 # 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18KS6C SHELVES PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358002 Shelf-freezer,full width 5303299664 Spacer,shelf 240545001...
- Page 8 Publication No. FRT18KS6C 5995389052 SYSTEM 04/03...
- Page 9 A = FRT18KS6C (FRT18KS6CW0) B = FRT18KS6C (FRT18KS6CQ0) POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18KS6C SYSTEM...
-
Page 10: Wiring Schematic
Publication No. FRT18KS6C 5995389052 WIRING SCHEMATIC 04/03... -
Page 11: Wiring Diagram
FRT18KS6C Publication No. 5995389052 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
