PRODUCT NO.
BASE MODEL NO.
FRT18KC3BW4
FRT18KC3B
MARKET
North America
ENERGY GUIDE - 218791461
OWNER'S GUIDE - 240400107
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
white
Publication No.
5995380168
021024
-EN/SERVICE /DCS
390
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18KC3B
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18KC3B and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT18KC3B

Summary of Contents for Frigidaire FRT18KC3B

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18KC3BW4 FRT18KC3B R134a white MARKET North America ENERGY GUIDE - 218791461 OWNER’S GUIDE - 240400107 SERVICE DATA SHEET - # 240379010 TOP MOUNT REFRIGERATOR Model No. ELECTROLUX HOME PRODUCTS, INC. FRT18KC3B P.O.
  • Page 2 Publication No. FRT18KC3BW4 5995380168 DOOR 10/02...
  • Page 3 FRT18KC3BW4 Publication No. 5995380168 DOOR POS. NO PART NO DESCRIPTION 240542103 Gasket-frzr door,white ,magnetic 240542106 Gasket-refr door,white ,magnetic 240534901 Rack-door 240534701 Rack-door,4A 240337703 Door-dairy,w/o graphics ,clear 240534801 Rack-door 240381301 Plug-button,white ,hinge brg hole ,(2) 240412501 Door,frzr ,white ,complete assy 240415201 Label-nameplate,white 240312403 Door Stop,white ,ref...
  • Page 4 Publication No. FRT18KC3BW4 5995380168 CABINET 10/02...
  • Page 5 FRT18KC3BW4 Publication No. 5995380168 CABINET POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462008 Cover-evap coil 240532102 Seal-coil cover 10*# 240524701 Wiring Harness,freezer section 5303208309 Plug-hole,factory test 240366801...
  • Page 6 Publication No. FRT18KC3BW4 5995380168 SHELVES 10/02...
  • Page 7 FRT18KC3BW4 Publication No. 5995380168 SHELVES POS. NO PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 5303282284 Shelf-freezer,"table type" 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 241500701 Socket-light/lamp 240352701 Control Box 17*# 240388701 Wiring Harness,control box 240360801 Knob,temp control...
  • Page 8 Publication No. FRT18KC3BW4 5995380168 SYSTEM 10/02...
  • Page 9 FRT18KC3BW4 Publication No. 5995380168 SYSTEM POS. NO PART NO DESCRIPTION 240406404 Condenser,static 5303208866 Spacer,condenser tube ,black 5308000296 Bracket,condenser mtg ,(4) 5308009617 Washer,ext tooth lock ,#10 ,grounding 218944001 Drier-filter,R134a System 240388701 Wiring Harness,control box 6* # 240375401 Wiring Harness,machine compt ,w/service cord 6* # 240524701 Wiring Harness,freezer section...

  • Page 10: Wiring Schematic

    Publication No. FRT18KC3BW4 5995380168 WIRING SCHEMATIC 10/02...

  • Page 11: Wiring Diagram

    FRT18KC3BW4 Publication No. 5995380168 WIRING DIAGRAM # = Fast-moving Parts 10/02 * = Non-Illustrated Parts...
