Frigidaire FRT18KS5A Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT18KS5A:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT18KS5AQ8
FRT18KS5A
FRT18KS5AW8
FRT18KS5A
MARKET
North America
WIRING DIAGRAM - # 240379010
OWNER'S GUIDE - # 240400109
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995389334
030423
-EN/SERVICE /DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18KS5A
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18KS5A
Summary of Contents for Frigidaire FRT18KS5A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18KS5AQ8 FRT18KS5A R134a bisque FRT18KS5AW8 FRT18KS5A R134a white MARKET North America WIRING DIAGRAM - # 240379010 OWNER’S GUIDE - # 240400109 SERVICE DATA SHEET - # 240379010 TOP MOUNT REFRIGERATOR Model No.
- Page 2 Publication No. FRT18KS5A 5995389334 DOOR 04/03...
- Page 3 FRT18KS5A Publication No. 5995389334 DOOR A = FRT18KS5A (FRT18KS5AQ8) B = FRT18KS5A (FRT18KS5AW8) POS. NO PART NO DESCRIPTION 240542103 Gasket-frzr door,white ,magnetic 240542106 Gasket-refr door,white ,magnetic 240337703 Door-dairy,w/o graphics ,clear 240381302 Plug-button,bisque ,hinge brg hole ,(2) 240381301 Plug-button,white ,hinge brg hole ,(2) 240410202 Door-frzr,bisque ,complete assy 240410201...
- Page 4 Publication No. FRT18KS5A 5995389334 CABINET 04/03...
- Page 5 FRT18KS5A Publication No. 5995389334 CABINET A = FRT18KS5A (FRT18KS5AQ8) B = FRT18KS5A (FRT18KS5AW8) POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462010 Cover-evap coil 240568601 Seal-coil cover...
- Page 6 Publication No. FRT18KS5A 5995389334 SHELVES 04/03...
- Page 7 FRT18KS5A Publication No. 5995389334 SHELVES A = FRT18KS5A (FRT18KS5AQ8) B = FRT18KS5A (FRT18KS5AW8) POS. NO PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358002 Shelf-freezer,full width 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 241500701 Socket-light/lamp 240352701...
- Page 8 Publication No. FRT18KS5A 5995389334 SYSTEM 04/03...
- Page 9 FRT18KS5A Publication No. 5995389334 SYSTEM A = FRT18KS5A (FRT18KS5AQ8) B = FRT18KS5A (FRT18KS5AW8) POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness,machine compt ,w/electric cord 6* # 240388701 Wiring Harness,control box 6* # 240524701 Wiring Harness,freezer section 14 # 5303918208 Defrost Heater Kit...
-
Page 10: Wiring Schematic
Publication No. FRT18KS5A 5995389334 WIRING SCHEMATIC 04/03... -
Page 11: Wiring Diagram
FRT18KS5A Publication No. 5995389334 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
