3.2. Main screen

The main screen of the application contains a series of fields with information about heat pump operation.
Status
Operation program

3.3. Active components

This field shows the main components of the heat pump that are activated. A consumption bar is also shown for the compressor and
modulating circulator pumps.
Aerothermal fan activated (only for ecoGEO B/C versions)
Brine pump activated
Compressor in start-up phase
Compressor activated
Compressor in shut-down phase
Production pump activated
Heating units activated
Cooling units activated
Auxiliary heating unit activated
HTR system activated (only for ecoGEO B/C versions)
// Mon
7
Active components
Figure 3.2. Description of the main screen.
38
Date and time
4:5
Energy meter
5
Operation mode
User manual ecoGEO
