ecoGEO+ HP R454B GEN1

TECHNICAL MANUAL

MODEL:

SERVICE CONTACT:

Table of Contents

Need help?

Do you have a question about the ecoGEO+ HP R454B GEN1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ECOFOREST ecoGEO+ HP R454B GEN1

Page 1 HP R454B GEN1 TECHNICAL MANUAL MODEL: SERVICE CONTACT:...
Page 3: Table Of Contents
Contents General Information ................................5 1.1. Safety considerations ................................5 1.2. Disposal ....................................12 Heat pump installation ................................. 13 2.1. Transport and handling ................................ 13 2.2. Dimensions and connections ............................... 13 2.3. Unpacking .................................... 14 2.4. Assembly and disassembly of the covers ..........................14 2.5.
Page 4 Technical manual ecoGEO+ HP 9.1. Power and consumption curves ............................54 9.2. HTR curves ................................... 56 10. Technical data table ................................57 11. Symbols ....................................60...
Page 5: General Information
Technical manual ecoGEO+ HP 1. General Information ▪ This manual contains the necessary information to install the heat pump. Read this manual carefully before installing the equipment. Keep this manual handy for future reference. This manual contains two different kinds of warnings that should be heeded. ▪...
Page 6 Refrigerant Ecoforest heat pumps may contain different types of refrigerants depending on the model. The refrigerants used by Ecoforest are not harmful to the environment as they do not contain chlorine and therefore do not contribute to the destruction of the ozone layer.
Page 7 Do not apply a flame until the circuit is completely empty. ▪ ake sure that any replacement components in the refrigerant circuit or the heat pump are supplied or approved by Ecoforest. Other parts may result in the ignition of refrigerant in the atmosphere from a leak. ▪...
Page 8 If the problem cannot be corrected immediately, but it is nonetheless necessary to continue with the operation, a suitable temporary solution, agreed with Ecoforest's technical department, must be used. This must be reported to the owner of the equipment so that all parties can be informed.
Page 9 Technical manual ecoGEO+ HP Observe the following warnings during the recovery and charging processes: ▪ hen transferring refrigerant to recovery cylinders, make sure that only suitable refrigerant DANGER! recovery cylinders are used. Make sure that the correct number of cylinders are available to hold the total system charge.
Page 10 Technical manual ecoGEO+ HP ▪ he system must be tested for leaks when charging has been completed but before start-up. A leak DANGER! test should be carried out before the equipment is left to operate normally. ▪ ealed electrical and intrinsically safe components must be replaced when broken or faulty. Hydraulic installation Installation and subsequent interventions on the heating, brine or DHW circuits must only be performed by authorised personnel in accordance with applicable local regulations and the instructions provided in this manual.
Page 11 DANGER! ▪ he heat pump must be supplied with an external switch that can shut off all the circuits. Ecoforest recommend installing one external automatic breaker in each external power supply that provide full disconnection under overvoltage category III (control, internal auxiliary equipment and drive).
Page 12: Disposal
The heat pump contains refrigerant. Ecoforest uses refrigerants that are not harmful to the environment, but once their useful life cycle is over, the refrigerant must be recovered so that it can be recycled or disposed of in accordance with current regulations.
Page 13: Heat Pump Installation
Technical manual ecoGEO+ HP 2. Heat pump installation 2.1. Transport and handling The heat pump must be transported vertically and not exposed to adverse weather conditions. It can be lain carefully on its rear side to facilitate transportation to the installation site. ▪...
Page 14: Unpacking
Technical manual ecoGEO+ HP ecoGEO+ HP 400/575 170 R454B 1009 1074 Table 2.2. Key to overall dimensions in mm. 2.3. Unpacking To unpack the heat pump, remove the wooden box carefully, remove the pallet anchoring screws and perform a check to make sure the heat pump has not been damaged during transportation.
Page 15 Technical manual ecoGEO+ HP Figure 2.3. Disassembly of the covers of the ecoGEO+ HP models. ▪ During cover disassembly, take care to remove the control panel cable without damaging it. NOTE...
Page 16: Recommended Positioning
Technical manual ecoGEO+ HP 2.5. Recommended positioning ▪ he ecoGEO HP heat pumps range must be installed in a place where they are not accessible to the DANGER! general public. Choose a dry place where there is no risk of frost. Avoid installation against bedroom walls or walls of other rooms where noise emissions can be annoying.
Page 17 Technical manual ecoGEO+ HP Description Distances (mm) Minimum distance from the lower ventilation of the technical room to the evacuation in the heat pump. > 0 Minimum height of the lower ventilation of the technical room to the floor. 20 - 100 Maximum height of the lower ventilation of the technical room to the floor Minimum height of the lower ventilation of the technical room to the floor.
Page 18 Technical manual ecoGEO+ HP ▪ For mechanical ventilation, the lower edge of the openings that extract air from the machine room must not be more than 100 mm above the floor. The R454B refrigerant has a higher density than air, so an opening must be installed above the evacuation, so that fresh air enters and mixes with the refrigerant evacuated from the unit.
Page 19: Service Areas
Technical manual ecoGEO+ HP 2.6. Service areas The minimum recommended distances to be left around the heat pump to facilitate installation, start-up and maintenance work are indicated below. Figure 2.8. Minimum recommended service areas around the heat pump (amounts in mm). ▪...
Page 20: Hydraulic Installation
Technical manual ecoGEO+ HP 3. Hydraulic installation ▪ The installation schemes included from here on should be considered simply as a guide. ▪ The design of the hydraulic installation must be performed by qualified personnel and in accordance NOTE with applicable local regulations. ▪...
Page 21: Heating / Cooling Circuit
Technical manual ecoGEO+ HP Figure 3.1. Source circuit connection options. Installation instructions Follow the instructions below to wire the source circuit. ▪ Install the necessary components to carry out the filling/discharge of the return pipe. ▪ Install a particulate filter in the return pipe with a mesh size no greater than 1 mm. It is recommended to install shut off valves immediately before and after the filter to make it easier to clean or replace.
Page 22 Technical manual ecoGEO+ HP situation in the emission system. For this, the installation can be planned to operate with at least one of the emission circuits open continuously. If all the emission circuits can be closed, it is recommended to install a differential pressure valve between the outlet and inlet pipes of the heat pump.
Page 23 Technical manual ecoGEO+ HP FBus2 AI20 AI19 DI11 DI13 DI10 DI12 DI14 AI12 AI13 AI14 AI15 AI16 DO10 DO20 DO16 AI17 AI11 DO18 AI18 DO12 DO17 DO19 DO12 Figure 3.4. Wiring scheme using one buffer storage tanks (ecoGEO+ HP3 models). Outlet units These can manage as many as five different outlet temperatures.
Page 24: Dhw Circuit
Technical manual ecoGEO+ HP FBus2 AI20 AI19 DI11 DI13 DI10 DI12 DI14 AI12 AI13 AI14 AI15 AI16 DO10 AI17 AI11 DO18 AI18 DO17 DO16 DO15 DO12 DO19 DO14 Figure 3.5. Wiring scheme using two buffer storage tanks with simultaneous production (ecoGEO+ HP1 models). Installation instructions Follow the instructions below to connect the heating / cooling circuit.
Page 25: Pool Circuit
Technical manual ecoGEO+ HP AI12 AI12 AI20 AI20 AI11 AI11 DO17 DO17 DO19 Figure 3.6. Wiring scheme of the DHW circuit Installation instructions Follow the instructions below to wire the DHW circuit. • In the ecoGEO+ HP models, install a particulate filter in the return pipe to the heat pump with a mesh size no greater than 1 mm.
Page 26 Technical manual ecoGEO+ HP AI12 AI19 AI19 AI20 AI20 AI11 DO17 DO19 Figure 3.7. Pool production wiring schemes...
Page 27: Filling And Discharge Circuits
Technical manual ecoGEO+ HP 4. Filling and discharge circuits ▪ uring filling work on the hydraulic circuits, take special care to prevent liquid from spilling on the DANGER! internal electrical heat pump components, which could cause personal injury due to electrocution and/or poor equipment operation.
Page 28 Technical manual ecoGEO+ HP Figure 4.1. Filling the source circuit.
Page 29: Electrical System
Technical manual ecoGEO+ HP 5. Electrical system ▪ efore performing any operation on the electrical panel, disconnect the power supply. DANGER! ▪ emember that the heat pump has more than one electrical power supply. ▪ coforest recommends that an external switch be installed for each of the electrical power sources (control, internal auxiliary equipment, and inverter).
Page 30 Technical manual ecoGEO+ HP Several installation devices are controlled from the heat pump electrical panel. Some are internal and other are installed externally. The internal components are connected to the electrical panel in the factory. Depending on the installation that the heat pump is going to be connected to, in addition to the power supply, it may be necessary to connect various temperature probes (analogue inputs AIxx), control signals from thermostats or other external equipment (digital inputs DIxx) on/off switching of pumps and/or valves (digital outputs DOxx) or regulation of pumps and/or valves (analogue outputs AOxx).
Page 31 Technical manual ecoGEO+ HP Analogue inputs (AIxx) These terminals are used to connect external temperature probes. Only passive NTC temperature probes can be connected, so cable connection polarity is not important. If necessary, use extension cables with a maximum length of 50 m and a minimum diameter of 0,75 mm .
Page 32 Technical manual ecoGEO+ HP 24Vac Figure 5.5. Example of digital input connections with 24Vac voltage. Analogue outputs (AOxx) These terminals send analogue 0-10Vdc regulation signals to modulate the control of outlet units with mixture, aerothermal source units with variable speed fan, external auxiliary boilers, etc. On the other hand, these connectors have a 24Vac power supply terminal to supply the modulating valve motor.
Page 33: Heat Pump Power Supply
III (control, internal auxiliary equipment and drive). Ecoforest ecoGEO+ HP heat pumps require two power supply points. One for the power supply of the control panel; this unit includes the power supply of the internal and external valves and also that of the regulation signals and the digital and analogue inputs. The other power supply is exclusively dedicated to the compressor.
Page 34 Technical manual ecoGEO+ HP To carry out the electrical installation, insert the power cables through the cable grommet holes at the back of the heat pump. Continue by connecting the cables to the power terminal block of the heat pump, as described in figures 5.9 and 5.10. Power supply of the control panel The control panel power supply is always single-phase;...
Page 35: External Protections
Technical manual ecoGEO+ HP 5.3. External protections It is equipped with a connector that can be connected to various types of external mechanical protections, such as flow switches, pressure switches, thermostats, etc. The ESS connector is used to connect these protections. The external protection devices are powered from the heat pump connector. Figure 5.11.
Page 36: External Production Equipment
Technical manual ecoGEO+ HP 5.6. External production equipment These are used to control production equipment handling of the various services, such as bypass valves or circulatory pumps. Description Signal Type Connector Digital output Activation 230Vac / 8A maximum Source pump Analogue output Valve regulation 0 –...
Page 37: External Auxiliary Equipment
Technical manual ecoGEO+ HP Description Signal Type Connector DG1 direct unit Digital output Activation 230Vac / 2A maximum Analogue input NTC 10K 25ºC Probe AI13 SG2 unit with mixture Analogue output Valve regulation 0 – 10Vdc Digital output Activation 230Vac / 2A maximum Analogue input NTC 10K 25ºC Probe AI14...
Page 38: Remote Services Production Control
Technical manual ecoGEO+ HP 5.11. Remote services production control The heat pump is equipped with digital inputs for remote control of production services. Description Signal Type Connector Control of electrical consumption (EVU) Digital input Voltage-free (0V) WINTER / SUMMER program selection Digital input Voltage-free (0V) Enable / disable DHW production...
Page 39 Technical manual ecoGEO+ HP Description Signal Type Connector DG1 direct unit heating request Digital input 24Vdc / 24Vac signal DG1 direct unit cooling request Digital input 24Vdc / 24Vac signal SG2 mix unit heating request Digital input 24Vdc / 24Vac signal SG2 mix unit cooling request Digital input 24Vdc / 24Vac signal...
Page 40: Remote Control By Bus
Technical manual ecoGEO+ HP FBus2 Figure 5.13. Example of connection of thT terminals. Installation without interior terminals The ecoGEO+ heat pumps can also be used in installations that do not have any type of interior terminal to generate request signals. In these cases, a continuous request can be imposed at the digital input of the unit to activate by selecting the appropriate control logic in the controller.
Page 41: Energy Meter
120 Ohm heater between Rx+/Tx+ and Rx-/Tx- in the first and last terminal to prevent possible communication problems. ▪ To install the device supplied by Ecoforest, follow the steps in the manufacturer's installation manual included with the equipment. It is necessary to configure a 100 address on the measurement device for proper communication with your...
Page 42: R454B Leak Detector
5.15. R454B leak detector ▪ eak detection system installed. Unit must be powered except for service. DANGER! The heat pump allows MODBUS communication with R454B leak detectors supplied by Ecoforest. Before installing this sensor, carefully read its assembly instructions. Description Signal...
Page 43: Technical Specifications
Technical manual ecoGEO+ HP 7. Technical specifications 7.1. Component location Description Description Source inlet temp. probe Production outlet Production outlet temp. probe Production return Production inlet temp. probe Source outlet Suction pressure transducer Source return Discharge pressure transducer HTR outlet Source pressure transducer HTR return Production pressure transducer...
Page 44 Technical manual ecoGEO+ HP ecoGEO+ HP1 400 170 R454B / ecoGEO+ HP1 575 170 R454B...
Page 45 Technical manual ecoGEO+ HP ecoGEO+ HP1 400 170 R454B HTR / ecoGEO+ HP1 575 170 R454B HTR...
Page 46 Technical manual ecoGEO+ HP ecoGEO+ HP3 400 170 R454B / ecoGEO+ HP3 575 170 R454B...
Page 47 Technical manual ecoGEO+ HP ecoGEO+ HP3 400 170 R454B HTR / ecoGEO+ HP3 575 170 R454B HTR...
Page 48: Power Circuit Diagram
Technical manual ecoGEO+ HP 7.2. Power circuit diagram COIL Control power Drive Power Supply 400Vac supply 230Vac Tx/Rx J9 FBus1 J11 BMS2 J14 pLAN Tx/Rx J29 FBus2 24 Vac pCOOEM+ Serial Adress Serial Adress 2 4 8 2 4 8 TRAFO 230/24 BMS2...
Page 49: Electrical Connection Tables
Technical manual ecoGEO+ HP 7.3. Electrical connection tables DIGITAL OUTPUTS CONNECTIONS DESCRIPTION Connection terminal Controller terminal Type Signal Block I / DO1 pCOOEM+ / J16 / NO1 Activation 230Vac / 8A max Source circulation pump Block I / DO2 pCOOEM+ / J17 / Out2 Activation 230Vac / 8A max Production circulation pump Block I / DO3...
Page 50 Technical manual ecoGEO+ HP ANALOGUE INPUTS CONNECTIONS DESCRIPTION Connection terminal Controller terminal Type Signal Block II / AI1 pCOOEM+ / J2 / U1 NTC 10K 25°C Compressor suction temperature Block II / AI2 pCOOEM+ / J2 / U2 Radiometer 0-5Vdc Compressor suction pressure Block II / AI3 pCOOEM+ / J2 / U3...
Page 51 Technical manual ecoGEO+ HP DIGITAL INPUTS CONNECTIONS DESCRIPTION Connection terminal Controller terminal Type Signal Block II / DI1 pCOOEM+ / J7 / DI1 Voltage free (0V) Electrical consumption control (EVU) Block II / DI2 pCOOEM+ / J7 / DI2 Voltage free (0V) WINTER / SUMMER selection Block II / DI3 pCOOEM+ / J7 / DI3...
Page 52: Load Losses
Technical manual ecoGEO+ HP 7.4. Load losses Evaporator / Condenser ecoGEO+ HP 400 170 R454B / ecoGEO+ HP 575 170 R454B 2500 5000 7500 10000 12500 15000 17500 20000 22500 25000 Flow (l/h) ecoGEO+ HP 400 170 R454B / ecoGEO+ HP 575 170 R454B 1000 1500 2000...
Page 53: Operation Map
Technical manual ecoGEO+ HP 8. Operation map ecoGEO+ HP1/HP3 400/575 170 R454B 7; 65 35; 65 -18; 39 -20; 33 -20; 10 Brine / cooling outlet temperature (°C) Map area for use with variable speed circulating pumps, managed by the ecoGEO+ HP heat pump.
Page 54: Operation Curves
Technical manual ecoGEO+ HP 9. Operation curves 9.1. Power and consumption curves ecoGEO+ HP1/HP3 400/575 170 R454B BxW35 Max/min BxW55 Max/min Source inlet temperature (°C) BxW35 Max/min BxW55 Max/min Source inlet temperature (°C)
Page 55 Technical manual ecoGEO+ HP ecoGEO+ HP1/HP3 400/575 170 R454B BxW7 Max/min BxW18 Max/min Source inlet temperature (°C) BxW7 Max/min BxW18 Max/min Source inlet temperature (°C)
Page 56: Htr Curves
Technical manual ecoGEO+ HP 9.2. HTR curves ecoGEO+ HP1/HP3 400/575 170 R454B Heating T – Source T (°C) ompressor discharge T – DHW T (°C)
Page 57: Technical Data Table
Technical manual ecoGEO+ HP 10. Technical data table ▪ In the technical data tables, you will find a series of numbers in superscript format, the meaning of which is explained below: NOTE In compliance with EN 14511, this includes the consumption of the circulation pumps and the compressor driver.
Page 58 Technical manual ecoGEO+ HP HP1 400 170 R454B HP3 400 170 R454B Specification ecoGEO+ HP 400 170 R454B (HTR) Units (HTR) (HTR) Place of installation Indoors Type of source system Geothermal ✓ Heating, DHW with external storage tank and pool Application ✓...
Page 59 Technical manual ecoGEO+ HP HP1 575 170 R454B HP3 575 170 R454B Specification ecoGEO+ HP 575 170 R454B (HTR) Units (HTR) (HTR) Place of installation Indoors Type of source system Geothermal ✓ Heating, DHW with external storage tank and pool Application ✓...
Page 60: Symbols
Technical manual ecoGEO+ HP 11. Symbols DHW circuit 3-way valve open/closed Pool 3-way thermostatic valve Heating system 3-way modulating valve 0-10Vdc Cooling system Check valve NTC temperature probe Cut-off valve Relay thermostat Safety valve Differential pressure valve Data bus communication terminal Circulator pump Particulate filter Direct outlet unit...
Page 64 Parque Empresarial Porto do Molle l Rúa das Pontes, 25 l 36350 – Nigrán – Pontevedra.- (Spain) Tel.: +34 986 262 184 http://www.ecoforest.es TECHNICAL manual ecoGEO+ HP R454B Gen1 Version 02E/2025 The manufacturer reserves the right to make any necessary changes to the contents of this manual without prior notice.
