- Page 1 Basic ecoGEO HP ecoGEO Compact USER MANUAL MODEL: SERVICE CONTACT:...
-
Page 2: Table Of Contents
Contents General information ................................32 1.1. Safety considerations ................................32 1.2. Maintenance ..................................33 General description ................................34 2.1. Type description................................... 34 2.2. Operating principles ................................34 Controller guide ..................................37 3.1. Control panel ..................................37 3.2. Main screen ..................................38 3.3. -
Page 3: General Information
User manual ecoGEO 1. General information Thank you for purchasing an ECOFOREST ecoGEO heat pump. This manual contains information on the overall operation of the heat pump and on how to use the controller functions. The user can also find information on how to deal with anomalous heat pump performance and some of the most common comfort malfunctions that can be solved without external assistance. -
Page 4: Maintenance
User manual ecoGEO The heat pump contains R410A refrigerant. This refrigerant is not harmful to the environment as it does not contain chlorine, and therefore does not contribute to the destruction of the ozone layer. Under normal operation of the heat pump the toxicity of the refrigerant is nil and there is no risk of explosion. -
Page 5: General Description
User manual ecoGEO 2. General description 2.1. Type description The range of ecoGEO heat pumps is available in two structures, ecoGEO B and ecoGEO C. The ecoGEO C series includes a DHW storage tank that is integrated in the structure, while the ecoGEO B series is designed for installation with various external DHW storage tanks. - Page 6 User manual ecoGEO Electric energy consumed 20 - 25% Energy supplied Free energy extracted from the earth 100% 75 - 80% Figure 2.2. Operation of a geothermal heat pump in normal conditions. The ecoGEO heat pumps include the most advanced technologies to produce heat, cool air and DHW for your home economically and respecting the environment.
- Page 7 User manual ecoGEO ecoGEO heat pumps include most of the components needed for the installation or heating / cooling and DHW. This simplifies external installation, reducing costs and space. Intelligent, versatile and user-friendly management Direct connection to heating / cooling systems via underfloor heating, heaters or radiators. Control of several different outlet temperatures (up to 4 with the ecoGEO B/C and as many as 5 with the ecoGEO HP).
-
Page 8: Controller Guide
User manual ecoGEO 3. Controller guide ▪ The information included below corresponds to application versions launched after January 2016. Other versions, both earlier and later, may differ slightly from the contents found in this section. NOTE ▪ Screens or screen contents that are not shown, depending on the heat pump model and the settings configured by the technical service. -
Page 9: Main Screen
User manual ecoGEO 3.2. Main screen The main screen of the application contains a series of fields with information about heat pump operation. Date and time Status // 4:5 Energy meter 7 5 Operation program Operation mode Active components Figure 3.2. Description of the main screen. 3.3. -
Page 10: Mode
User manual ecoGEO 3.4. Mode This field shows the icons that indicate the operating modes that are active. Several operating modes can be viewed simultaneously, depending on the heat pump model and the configuration set up by the technical service. DIRECT HEATING Mode / DIRECT COOLING Mode The heat pump sends hot / cold water directly to the heating / cooling system and adjusts the power supply to the consumption of the home. -
Page 11: Operation Program
User manual ecoGEO Apart from the icons that define the operating modes, the following icons can also be found in this field. Operation This indicates thermal energy transfer between circuits. If the icon is shown continuously, this indicates normal heat pump operation. If the icon flashes, there is a heat pump protection activated. - Page 12 User manual ecoGEO ON + NIGHT SCHEDULE status The heat pump is on and available to activate all its functions, but performance is limited by night-time schedule programming. OFF status from control panel The heat pump is switched off from the front panel of the controller and is therefore not available to activate any of its functions.
-
Page 13: List Of User Menus
User manual ecoGEO 3.7. List of user menus Follow the instructions below to browse through the various user menus. Each menu has a series of screens that are used to change heat pump STATUS and OPERATION MODE, adjust comfort parameters and view desired information. //... -
Page 14: Parameter Adjustment
User manual ecoGEO 3.8. Parameter adjustment Take the following steps to change a parameter: Search for the screen containing the parameter that needs adjusting (see Section 3.7). With the cursor in position 1 press on to enter the screen and move the cursor to the parameter in position 2. Adjust the parameter in position 2 using buttons Press to accept and move the cursor to position 3. -
Page 15: Calendar Menu
User manual ecoGEO 3.10. CALENDAR Menu User menu /8 On/Off Schedule Heating /8 Date/Time Date/Time Day: Sunday This is used to adjust the day of the week, date (DD/MM/YY) and time (HH:MM 24-hour format) of the controller. Date: //5 Time: 7:5 Daily saving time Daily saving time... -
Page 16: Cooling Menu
User manual ecoGEO Heating groups Heating groups - + - + This can be used to adjust the heating target outlet temperatures programmed by the DG: SG: 5 technical service. Each ramp increases or decreased the outlet temperature by 2ºC. SG3: SG4: oom terminals... -
Page 17: Dhw/Legionella Prot. Menu
User manual ecoGEO Auxiliary cooling X Auxiliary cooling X This is used to enable the auxiliary cooling system in both EMERGENCY and SUPPORT mode. Emergency: Support: In EMERGENCY mode, the auxiliary system is activated automatically if there are any active alarms that prevent compressor start-up. -
Page 18: Pool Menu
User manual ecoGEO 3.14. POOL Menu User menu /8 DHW/Legionella prot Pool Information /8 Pool Pool Enable: Used to enable the POOL mode. In versions for ecoGEO B and ecoGEO C, it can be used to adjust the percentage of Winter program Minutes per hour: ... - Page 19 User manual ecoGEO oom terminals Room terminals SetT ealT H In installations with interior terminals equipped with bus communication (Th-T or TH T: 5 498 3 T: 45 4 sensors), it displays the interior setpoint temperature (Tcons), the current temperature 45...
-
Page 20: Alarms Menu
User manual ecoGEO Version Version Version: 5B Date: //5 This shows information about the application installed in the controller. Bios: 4 5//4 Boot: 45 4//3 Version firmw: 5 Firware version: 3.16. ALARMS Menu Press for quick access to the information menu from the main screen. User menu Pool Information... -
Page 21: Troubleshooting
User manual ecoGEO 4. Troubleshooting 4.1. Comfort deficiencies In the event of lack of comfort in any of the services, use the following table to identify the most common problems that users can solve on their own. Symptom Possible cause Remedy Where No power supply. -
Page 22: Alarm Messages
User manual ecoGEO If the problem cannot be solved using these instructions or abnormal heat pump operation is detected, please contact the technical service and request that the installation be checked. 4.2. Alarm messages The heat pump performs constant monitoring of multiple operation parameters. If any of these parameters is not within the normal range of values, the controller will activate an alarm and display a message showing the error, which will be recorded in the ALARMS menu. -
Page 23: Technical Specifications
User manual ecoGEO 5. Technical specifications ecoGEO ecoGEO ecoGEO ecoGEO Specification ecoGEO B/C 1-9 Units B/C1 B/C2 B/C3 B/C4 Place of installation Indoors Type of brine system Geothermal / Aerothermic / Hybrid ✓ ✓ ✓ ✓ Heating Application ✓ ✓ ✓... - Page 24 User manual ecoGEO ecoGEO ecoGEO ecoGEO ecoGEO Specification ecoGEO B/C 3-12 Units B/C1 B/C2 B/C3 B/C4 Place of installation Indoors Type of brine system Geothermal / Aerothermic / Hybrid ✓ ✓ ✓ ✓ Heating Application ✓ ✓ ✓ ✓ HTR - High temperature recovery system ✓...
- Page 25 User manual ecoGEO ecoGEO ecoGEO ecoGEO ecoGEO Specification ecoGEO B/C 5-22 Units B/C1 B/C2 B/C3 B/C4 Place of installation Indoors Type of brine system Geothermal / Aerothermic / Hybrid ✓ ✓ ✓ ✓ Heating Application ✓ ✓ ✓ ✓ HTR - High temperature recovery system ✓...
-
Page 26: Warranty And Technical Service
User manual ecoGEO Specification ecoGEO HP1 12-40 kW / HP3 12-40 kW Units HP1 12-40 HP3 12-40 Place of installation Indoors Type of brine system Geothermal Heating, DHW with external storage tank and ✓ Application pool ✓ Integrated active cooling ✓... - Page 27 User manual ecoGEO Specification ecoGEO HP1 15-70 kW / HP3 15-70 kW Units HP1 15-70 HP3 15-70 Place of installation Indoors Type of brine system Geothermal Heating, DHW with external storage tank and ✓ Application pool ✓ Integrated active cooling ✓...
- Page 28 User manual ecoGEO Specification ecoGEO HP1 25-100 kW / HP3 25-100 kW Units HP1 25-100 HP3 25-100 Place of installation Indoors Type of brine system Geothermal Heating, DHW with external storage tank and ✓ Application pool ✓ Integrated active cooling ✓...
-
Page 29: Manufacturer's Warranty
6.1. Manufacturer's warranty ECOFOREST is liable for lack of conformity of the product or its spare parts, in compliance with the current regulations of the country where the product is purchased. The warranty is only valid in the country where the product is purchased. - Page 31 ECOFOREST GEOTERMIA, S.L. Poligono industrial A pasaxe C/15 - nº22 - parcela 139 36316 - Vincios / Gondomar - Pontevedra (Spain) Tel.: +34 986 262 184 / +34 986 417 700 Fax: +34 986 262 186 e-mail: Info@ecoforest.es http://www.ecoforest.es The manufacturer reserves the right to make any necessary changes to the contents of this manual without prior notice.
