Table of Contents Notice for Users in the USA ..........................4 TCO'99 ................................5 Notice for Users in Europe ..........................7 Notice for Users in the UK ..........................8 Notice for Users in Australia ..........................8 Tips and safety precautions ..........................9 Product description ............................
Sharp Plaza, Mahwah, New Jersey 07430 TEL :1-800-BE-SHARP * As an ENERGY STAR Partner, SHARP has determined that this product meets the ENERGY STAR guidelines for energy efficiency. This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated due to environmental considerations.
Congratulations! You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. Why do we have environmentally labelled computers? In many countries, environmental labelling has become an established method for encouraging the adapta- tion of goods and services to the environment.
Page 5
TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO'99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire.
Notice for Users in Europe This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE.
"WARNING :THIS APPARATUS MUST BE EARTHED" Notice for Users in Australia Service Inquiries Please contact your dealer for service if required or contact Sharp Corporation of Australia on 1 300 13 50 22 for referral to your nearest Sharp authorized Service Center. Downloaded from:...
This monitor and its accessories may be up- monitor needs to be transported. graded without advance notice. Authorship rights to the Monitor Settings Adjustment Disk's program are held by Sharp Corporation. Do not reproduce it without Location permission. Do not use the monitor where ventilation is poor,...
Product description Front view Power button (p. 14) This button switches the monitor ON and OFF. Control Panel Power LED (p. 14) Green light: In use Orange light: Power saving mode or signal failure Lamp off: Power OFF buttons When the On Screen Display (OSD) Menu is displayed: These buttons are used to increase or decrease the value of a selected option.
Page 10
Product description Front view Note: Never block the ventilation Ventilation openings as this may lead to openings overheating inside the monitor and result in malfunction. Power terminal (p. 12) Remove the cover to see the power terminal. The AC adapter is connected here.
Connecting the monitor and turning the monitor on and off 5. Connect power cord to AC adapter. Connecting the monitor to a power source Use only the AC adapter supplied. 1. Remove the stand cover. Power cord (Rear View) Stand cover Lift one side Fitting the AC adapter inside the stand Wind the cord...
Connecting the monitor and turning the monitor on and off 2. Connect the RGB signal cable (purchased Connecting the monitor to a computer separately) to the INPUT 2 terminal. (PC etc.) INPUT 2 terminal When connecting, ensure that both the monitor and computer are switched off.
Connecting the monitor and turning the monitor on and off 2. Connect the USB cable. Changing between input terminals USB port: Downstream (2 ports) (INPUT 1 ↔ ↔ ↔ ↔ 2) ↔ When connected to two computers, use the INPUT button to switch between input signal terminals (i.e.
Page 14
Connecting the monitor and turning the monitor on and off 7. Check that the monitor details are displayed, Installing set-up information and the ICC then click [Apply]. profile 8. Click [OK], and close the window. 9. Remove the Monitor Settings Adjustment Depending on the computer or OS, it may be neces- Disk from the A drive sary to use the computer to operate the installation...
Page 15
Connecting the monitor and turning the monitor on and off 8. When [Models] is displayed, click on [Have Disk], Installing the ICC profile confirm that [Copy manufacturer's files from:] is Installing the monitor’s ICC profile. (If the set-up [A:], and click [OK]. information has already been installed, so too has the profile, and there is no need to install it.) 9.
Adjusting the screen display If necessary, the screen can be adjusted as follows. Adjustment lock function Automatic screen adjustment (p. 18) By disabling the control buttons (i.e. setting the lock) The CLOCK, PHASE, H-POS (horizontal position- any attempted changes to adjusted values will be ing) and V-POS (vertical positioning) functions can voided.
Adjusting the screen display Adjusting the screen automatically Automatic screen adjustment 1. Press the MENU button. The ADJUSTMENT Menu will be displayed. Options in MENU 1 (ADJUSTMENT) can be ad- justed automatically (CLOCK, PHASE, H-POS, V- POS). Note: When setting up the monitor or a connected computer for the first time, connecting an additional computer or after having changed an 2.
Adjusting the screen display MENU 1: ADJUSTMENT Manual screen adjustment Fine adjustments can be made using the On Screen Display (OSD) Menu provided. MENU 1: ADJUSTMENT CLOCK, PHASE, H-POS (horizontal positioning) and V-POS (vertical positioning) MANUAL: Individual menu options are manually MENU 2: GAIN CONTROL adjusted.
Page 19
Adjusting the screen display MENU 2: GAIN CONTROL MENU 3: WHITE BALANCE BRIGHT (brightness) and CONT (contrast) are WHITE BALANCE can be adjusted as necessary. optimized before shipment, but depending on the (As adjustments are made before shipment, there is type of computer being used, further adjustment no real necessity for further alteration.) may be necessary.
Page 20
Adjusting the screen display MENU 4: MODE SELECT The resolution can be adjusted Notes: To choose a menu option: SELECT button When adjustment complete: MENU button INPUT (Input mode) The input mode can be set ( buttons) VESA: VESA mode MAC: Power Macintosh mode 400 LINES (degree of resolution)
LCD panel. (A soft cloth such inquire at the shop where you purchased the as gauze or that used for lens cleaning is suitable.) monitor or your nearest Sharp authorized Service Center. (Never attempt this CAUTION! replacement on your own.)
Specifications Product specifications LCD display Power supply 18.1 inches (46 cm measured diagonally) AC100-240V (Use special AC adapter) Super-V and Anti Glare Low Reflection TFT LCD Temperature of operating environment module 5 - 35°C Resolution (max.) Power consumption SXGA 1280 x 1024 pixels 54W (4.5W when in power-saving mode) Displayable colors (max.) Dimensions (W x D x H, excluding rubber base)
Page 23
Specifications Signal timings Dot frequency Hsync Vsync Display mode VESA US text Power Macintosh series Sun Ultra series Notes: All are compliant only with non-interlace. Frequencies for Power Macintosh and the Sun Ultra series are reference values. If the monitor is receiving timing signals that are not compatible, [OUT OF TIMING] will appear. Follow your computer’s instruction manual to set the timing to be compatible with the monitor.
Page 24
Specifications Standards and compatibility DDC (Plug & Play) Power management This monitor supports the VESA DDC (Display Data The monitor is based on VESA DPMS (Display Channel) standard. Power Management Signaling). DDC is a signal standard for carrying out Plug & To activate the monitor's Power Management func- Play functions on the monitor or PC.
Instructions for attaching a VESA compliant arm An arm or stand based on the VESA standard 5. Remove the four screws and then remove the (purchased separately) can be attached to the stand from the monitor. monitor. Procurement of the arm or stand is at the custom- Four screws er's discretion.
Page 28
