TILE MATRIX
Allows one image to be expanded and displayed over multiple screens (up to 100) through a distribution
amplifier.
NOTE: Low resolution is not suitable for tiling to a large number of monitors. You can operate without a
distribution amplifier at a lower number of screens.
This function is released when selecting SCREEN SAVER or IMAGE FLIP except for NONE.
"DYNAMIC" and "ZOOM" will not work when Tile Matrix is activated.
When "DYNAMIC" or "ZOOM" is selected in ASPECT while executing TILE MATRIX, the setting will be applied
after completing the TILE MATRIX.
When TILE MATRIX is active the following functions are not available: MULTI PICTURE MODE, TEXT TICKER,
STILL, POINT ZOOM. Please refer to the POINT ZOOM function for more detail (see
If Media Player contents are played while TILE MATRIX is active, the image play timing might have a gap within
monitors.
This function is not available when SCREEN SAVER is active.
When HDMI of the TERMINAL SETTINGS is set to MODE2, TILE MATRIX is not available.
H MONITORS
Number of monitors arranged horizontally.
V MONITORS
Number of monitors arranged vertically.
POSITION
Select which section of the tiled image to be displayed on the monitor.
TILE COMP
Turns the TILE COMP feature on. If YES is set to the TILE COMP, you can adjust a displayed image size and
position by pressing the + button or the - button on the remote control.
ENABLE
Enables the TILE MATRIX settings.
TILE MATRIX MEM
When "INPUT" is selected, the TILE MATRIX setting is applied to each signal input.
COMMON
All settings in the TILE MATRIX are saved for all signal inputs.
INPUT
All settings in the TILE MATRIX are saved for the selected signal input.
ID CONTROL
Sets the monitor ID number from 1-100 and group ID from A-J. DETECTED MONITORS shows the number of all
monitors that are included in the daisy chain of connected LAN cables.
NOTE: Do not turn off the monitors' main power switch or put it into standby while AUTO ID/IP SETTING or
AUTO ID/IP RESET is activating.
The Group ID is made of multiple selections.
AUTO ID/IP SETTING
When "SET" is selected, AUTO ID/IP SETTING window is shown.
Do not connect network devices between the monitors connected with LAN.
SETTING ITEM
Select an item from [MONITOR ID], [IP ADDRESS] and [ID and IP].
MONITOR ID
When "YES" is selected the monitor ID numbers are set automatically for all monitors.
IP ADDRESS
Set the first octet to the third octet at "BASE ADDRESS".
The fourth octet is automatically set from "1" and counting up to the number of monitors connected with LAN.
"BASE ADDRESS" is shown when "IP ADDRESS" or "ID and IP" is selected at SETTING ITEM.
ID and IP
Set "MONITOR ID" and "IP ADDRESS".
BASE NUMBER
Set base number within 100 for the master monitor.
The other monitors that follow in the LAN chain will be given an individual monitor ID automatically. The monitor
ID given to each monitor counts up based on the base number of the master monitor. The monitor ID range is
1 to 100. Please choose a starting number that is low enough to include all connected monitors.
BASE ADDRESS
When "YES" is set, the monitor IP ADDRESS is set automatically for all monitors.
ID/IP SETTING
When "YES" is set, all settings in the AUTO ID/IP SETTING are activated.
START
DETECTED
This item is shown after "SETTING ITEM" is selected and "ID/IP ADDRESS START" is set to "YES".
MONITORS
If the detected number of monitors and the actual number of MONITOR IDs assigned are different, select
"RETRY" to recount the monitors.
If the shown number is correct, set "CONTINUE".
AUTO ID/IP RESET
When "RESET" is selected, AUTO ID/IP RESET window is shown.
RESET ITEM
Select a setting from [MONITOR ID], [IP ADDRESS], and [ID and IP].
When the number of monitors connected with LAN is changed, please select the same item that you selected at
"SETTING ITEM" in the AUTO ID/IP SETTING and then run the "AUTO ID/IP RESET".
ID/IP RESET START When "YES" is set, the setting of selected item at RESET ITEM returns to default setting.
When the setting returns to default setting, "FINISH!!" is displayed.
NOTE: After "ID/IP RESET START" is activated, the individual settings for "MONITOR ID" and "IP ADDRESS" will
be reset even though the monitor's are connected with LAN.
DETECTED
Displays the number of detected monitors.
MONITORS
COMMAND
When "ON" is set, a command is sent to all monitors connected with LAN cables.
TRANSFER
RESET
Resets all settings within the MULTI DISPLAY menu back to the factory setting.
English-40
page
59).
