GAMMA
Allows you to manually select the brightness level of grayscale. There are five selections: sRGB, L STAR,
DICOM SIM. and CST. We recommend to show grayscale image data on screen.
sRGB: GAMMA setting for sRGB.
L STAR: GAMMA setting for the CIELAB color space Lab.
DICOM SIM.: DICOM GSDF (Grayscale Standard Display Function) is typically used for medical imaging.
CST: CUSTOM VALUE can be adjusted when CST is selected as the GAMMA SELECTION setting.
CUSTOM VALUE: The gamma value is selected from the range from 0.5 to 4.0 in 0.1 steps.
100
80
60
40
20
BLACK
Adjusts the black luminance.
RED
Adjusts the color gamut.
GREEN
BLUE
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
COLOR VISION EMU
Previews various typical human vision deficiencies and is useful for evaluating how people who have such
deficiencies will perceive colors. This preview is available in four modes: Types P (Protanopia), D (Deuteranopia) and
T (Tritanopia) emulate color vision dichromacy, and Grayscale can be used for evaluating contrast legibility.
NOTE: Depending on the vision of the user, including those with color vision deficiency, there will be a variation in
how the screen's color is seen and experienced.
A simulation is used to illustrate the view of those with a color vision deficiency. It is not their actual view. The
simulation is a reproduction of those with a strong color vision mode of type P, type D or type T. People with a slight
color vision deficiency will experience little to no difference compared to those with normal color vision.
UNIFORMITY
This function electronically compensates the slight variations in the white uniformity level as well as deviations
in color that may occur throughout the screen area. These variations are characteristic of LCD panel technology.
This function improves the color reproduction and evens out the non-uniformity in luminance of the monitor.
NOTE: A higher number produces a better effect, but may also reduce the contrast ratio.
METAMERISM
Compensates the visual color difference with other monitors.
If you prefer to get the color reproduction to be closer to the Picture Mode setting, set this function to OFF.
OIUEN:
- When the selected PICTURE MODE is different from your computer's ICC color profile, you may experience
inaccurate color reproduction.
- MultiProfiler software, developed by NEC Display Solutions, is highly recommended to provide extended color
management features such as ICC profile Emulation and Printer Emulation. The latest MultiProfiler software is
available on the NEC Display Solutions website.
SAMPLE OF PRESET GAMMA
0
0
64
128
GRAY STEP [0-255]
SAMPLE OF RGB GAMUT SETTING
LCD NATIVE GAMUT
GREEN MODIFIED
GREEN
SETTING
RANGE
WHITE
BLUE
0
0.1
0.2
0.3
0.4
0.5
x
L*
sRGB
DICOM SIM.
Custom 1.8
Custom 2.2
192
255
RED
0.6
0.7
0.8
English-30
