ASPECT
NORMAL
FULL
WIDE
DYNAMIC
1:1
ZOOM
ZOOM
HZOOM
VZOOM
H POS
V POS
ADVANCED
OVER SCAN
HDMI1, HDMI2, HDMI3, MP, OPTION*
1
inputs only
ON
OFF
AUTO
DEINTERLACE
ON
OFF
TELECINE
HDMI1, HDMI2, HDMI3, MP inputs only
ADAPTIVE
CONTRAST*
2
HDMI1, HDMI2, HDMI3, MP inputs only
*1: This function depends on which Option Board you are using.
*2: If SPECTRAVIEW ENGINE is ON, this function is grayed out.
Select the aspect ratio of the screen image.
NOTE: When the ASPECT is set to DYNAMIC, the image will be changed to FULL image before IMAGE FLIP,
then start IMAGE FLIP.
When the ASPECT is DYNAMIC or ZOOM, the image will be changed to FULL image before TILE MATRIX,
and then start TILE MATRIX. After TILE MATRIX, the ASPECT will be returned to the previous ASPECT or set
ASPECT during TILE MATRIX.
If SCREEN SAVER is set, the ASPECT setting automatically changes to FULL from what you set. Once SCREEN
SAVER is off the ASPECT setting will go back to the setting that you originally set.
This function is not available when MOTION in SCREEN SAVER is active.
When the ASPECT is set to DYNAMIC or ZOOM while TILE MATRIX is set to active, after releasing
TILE MATRIX, DYNAMIC or ZOOM will be active.
POINT ZOOM function has limitations, please refer to POINT ZOOM (See
Zoom is also not available for an image with input resolution at 3840 x 2160 (60 Hz) and 4096 x 2160 (60 Hz).
Shows the aspect ratio as it is sent from the source.
Fills the entire screen.
Expands a 16:9 letterbox signal to fill the entire screen.
Expands 4:3 pictures to fill the entire screen with non-linearity image. Part of the outside image area will be cut
off due to expansion.
Shows the image in a 1 by 1 Pixel format. (If the input resolution is higher than the recommended resolution,
the image will be scaled down to fit the screen.)
Expands/reduces the image.
NOTE: The areas of the expanded image that are outside of the active screen area are not shown. The reduced
image may have some image degradation.
Maintains the aspect ratio while zooming.
Horizontal zoom value.
Vertical zoom value.
Horizontal position.
Vertical position.
Some video formats may require different scanning modes in order to best display the image.
Image size is larger than what can be displayed. Some images will have cropped edges.
Approximately 95% of the image will be shown on the screen.
Image size stays within the display area. The whole image is displayed on the screen. This setting may cause
distorted image at the edges.
NOTE: When you use a computer with HDMI out, please set "OFF".
Image size is set automatically.
NOTE: This function is not available if input signal is MP.
Selects the IP (Interlace to Progressive) conversion function.
NOTE: IMAGE FLIP is not available. When SUPER is selected in INPUT CHANGE and displayed, this function
cannot be changed.
Converts interlaced signals to progressive. This is the default setting.
Disables IP conversion. This setting is best suited for motion pictures but increases the risk of image retention.
Automatically senses the sources frame rate for optimal picture quality.
NOTE: Set DEINTERLACE to ON if TELECINE is AUTO.
Sets the level of adjustment for dynamic contrast.
If HIGH is set, the image is displayed clearly but it makes brightness unstable due to the wide gap of contrast
variation.
English-34
