PRODUCT NO.
BASE MODEL NO.
FRS26ZPHB3
FRS26ZPH
FRS26ZPHD3
FRS26ZPH
FRS26ZPHQ3
FRS26ZPH
FRS26ZPHW3
FRS26ZPH
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218954000
SERVICE DATA SHEET - # 218909401
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
bisque
R134a
white
Publication No.
5995343596
000919
-EN/SERVICE /DJH
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZPH
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26ZPH and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS26ZPH

Summary of Contents for Frigidaire FRS26ZPH

  • Page 1: Side By Side

    PRODUCT NO. BASE MODEL NO. FRS26ZPHB3 FRS26ZPH FRS26ZPHD3 FRS26ZPH FRS26ZPHQ3 FRS26ZPH FRS26ZPHW3 FRS26ZPH MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218954000 SERVICE DATA SHEET - # 218909401 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG...

  • Page 2: Freezer Door

    Publication No. FRS26ZPH 5995343596 FREEZER DOOR 09/00...
  • Page 3 A = FRS26ZPH (FRS26ZPHB3) B = FRS26ZPH (FRS26ZPHD3) C = FRS26ZPH (FRS26ZPHQ3) D = FRS26ZPH (FRS26ZPHW3) POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZPH FREEZER DOOR PART NO DESCRIPTION 215734323 A - - - Gasket-frzr door,black ,magnetic...

  • Page 4: Refrigerator Door

    Publication No. FRS26ZPH 5995343596 REFRIGERATOR DOOR 09/00...
  • Page 5 A = FRS26ZPH (FRS26ZPHB3) B = FRS26ZPH (FRS26ZPHD3) C = FRS26ZPH (FRS26ZPHQ3) D = FRS26ZPH (FRS26ZPHW3) POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZPH REFRIGERATOR DOOR PART NO DESCRIPTION 215734324 A - - - Gasket-refr door,black ,magnetic...
  • Page 6 Publication No. FRS26ZPH 5995343596 CABINET 09/00...
  • Page 7 A = FRS26ZPH (FRS26ZPHB3) B = FRS26ZPH (FRS26ZPHD3) C = FRS26ZPH (FRS26ZPHQ3) D = FRS26ZPH (FRS26ZPHW3) POS. NO 30A* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZPH CABINET PART NO DESCRIPTION 215637602 A B C D Cover-air duct 215637402...
  • Page 8 Publication No. FRS26ZPH 5995343596 CABINET 09/00...
  • Page 9 A = FRS26ZPH (FRS26ZPHB3) B = FRS26ZPH (FRS26ZPHD3) C = FRS26ZPH (FRS26ZPHQ3) D = FRS26ZPH (FRS26ZPHW3) POS. NO 101* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZPH CABINET PART NO DESCRIPTION 218249802 A B C D Seal-coil cover,(2) 5303289036...
  • Page 10 Publication No. FRS26ZPH 5995343596 SHELVES 09/00...
  • Page 11 A = FRS26ZPH (FRS26ZPHB3) B = FRS26ZPH (FRS26ZPHD3) C = FRS26ZPH (FRS26ZPHQ3) D = FRS26ZPH (FRS26ZPHW3) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZPH SHELVES PART NO DESCRIPTION 5303298147 A B C D Trim-basket 218298003 A B C D...
  • Page 12 Publication No. FRS26ZPH 5995343596 CONTROLS 09/00...
  • Page 13 A = FRS26ZPH (FRS26ZPHB3) B = FRS26ZPH (FRS26ZPHD3) C = FRS26ZPH (FRS26ZPHQ3) D = FRS26ZPH (FRS26ZPHW3) POS. NO 13 # 15 # 17A* 21 # 23 # 114# 141* 143* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZPH CONTROLS...
  • Page 14 Publication No. FRS26ZPH 5995343596 SYSTEM 09/00...
  • Page 15 A = FRS26ZPH (FRS26ZPHB3) B = FRS26ZPH (FRS26ZPHD3) C = FRS26ZPH (FRS26ZPHQ3) D = FRS26ZPH (FRS26ZPHW3) POS. NO 5303208866 5303289026 5304406721 5303289029 5* # 13 # 14 # 15 # 5308000110 5304415956 21 # 29 # 30 # 5308000039 5303001199...
  • Page 16 Publication No. FRS26ZPH 5995343596 DISPENSER 09/00...
  • Page 17 A = FRS26ZPH (FRS26ZPHB3) B = FRS26ZPH (FRS26ZPHD3) C = FRS26ZPH (FRS26ZPHQ3) D = FRS26ZPH (FRS26ZPHW3) POS. NO 17A* 35 # 38 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZPH DISPENSER PART NO DESCRIPTION 218832301 A B C D...

  • Page 18: Ice Container

    Publication No. FRS26ZPH 5995343596 ICE CONTAINER 09/00...
  • Page 19 A = FRS26ZPH (FRS26ZPHB3) B = FRS26ZPH (FRS26ZPHD3) C = FRS26ZPH (FRS26ZPHQ3) D = FRS26ZPH (FRS26ZPHW3) POS. NO 15 # 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZPH ICE CONTAINER PART NO DESCRIPTION 5304404344 A B C D...

  • Page 20: Ice Maker

    Publication No. FRS26ZPH 5995343596 ICE MAKER 09/00...
  • Page 21 A = FRS26ZPH (FRS26ZPHB3) B = FRS26ZPH (FRS26ZPHD3) C = FRS26ZPH (FRS26ZPHQ3) D = FRS26ZPH (FRS26ZPHW3) POS. NO 11 # 12 # 13 # 15 # 17 # 141* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZPH ICE MAKER...

  • Page 22: Wiring Schematic

    Publication No. FRS26ZPH 5995343596 WIRING SCHEMATIC 09/00...

  • Page 23: Wiring Diagram

    FRS26ZPH Publication No. 5995343596 WIRING DIAGRAM # = Fast-moving Parts 09/00 * = Non-Illustrated Parts...
