PRODUCT NO.
BASE MODEL NO.
FRS26ZRGB8
FRS26ZRG
FRS26ZRGD8
FRS26ZRG
FRS26ZRGW8
FRS26ZRG
MARKET
North American
WIRING DIAGRAM - # 218875901
OWNER'S GUIDE - # 218955100
SERVICE DATA SHEET - # 218909400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
white
Publication No.
5995325809
990716
-EN/SERVICE/KB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZRG
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26ZRG and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS26ZRG

Summary of Contents for Frigidaire FRS26ZRG

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26ZRGB8 FRS26ZRG R134a black FRS26ZRGD8 FRS26ZRG R134a almond FRS26ZRGW8 FRS26ZRG R134a white MARKET North American WIRING DIAGRAM - # 218875901 OWNER’S GUIDE - # 218955100 SERVICE DATA SHEET - # 218909400 SIDE BY SIDE REFRIGERATOR...

  • Page 2: Freezer Door

    Publication No. FRS26ZRG 5995325809 FREEZER DOOR 07/99...
  • Page 3 FRS26ZRG Publication No. 5995325809 FREEZER DOOR A = FRS26ZRG (FRS26ZRGB8) B = FRS26ZRG (FRS26ZRGD8) C = FRS26ZRG (FRS26ZRGW8) POS. NO PART NO DESCRIPTION 215734323 A - - Gasket-frzr door,black ,magnetic 215734303 - B - Gasket-frzr door,almond ,magnetic 215734313 - - C Gasket-frzr door,white ,magnetic 5303288950 A B C...

  • Page 4: Refrigerator Door

    Publication No. FRS26ZRG 5995325809 REFRIGERATOR DOOR P58R0078 07/99...
  • Page 5 FRS26ZRG Publication No. 5995325809 REFRIGERATOR DOOR A = FRS26ZRG (FRS26ZRGB8) B = FRS26ZRG (FRS26ZRGD8) C = FRS26ZRG (FRS26ZRGW8) POS. NO PART NO DESCRIPTION 215734324 A - - Gasket-refr door,black ,magnetic 215734304 - B - Gasket-refr door,almond ,magnetic 215734314 - - C Gasket-refr door,white ,magnetic 215403201 A B C...
  • Page 6 Publication No. FRS26ZRG 5995325809 CABINET 07/99...
  • Page 7 FRS26ZRG Publication No. 5995325809 CABINET A = FRS26ZRG (FRS26ZRGB8) B = FRS26ZRG (FRS26ZRGD8) C = FRS26ZRG (FRS26ZRGW8) POS. NO PART NO DESCRIPTION 215637602 A B C Cover-air duct 5303209814 A B C Nut,"U" type ,8-15(A) ,fan mtr mtg 215637401 A B C Cover-evap coil,lower 10A* 5308009617...
  • Page 8 Publication No. FRS26ZRG 5995325809 SHELVES 07/99...
  • Page 9 FRS26ZRG Publication No. 5995325809 SHELVES A = FRS26ZRG (FRS26ZRGB8) B = FRS26ZRG (FRS26ZRGD8) C = FRS26ZRG (FRS26ZRGW8) POS. NO PART NO DESCRIPTION 5303298147 A B C Trim-basket 218298003 A B C Shelf-freezer,sliding ,wire 5304405879 A B C Shelf-freezer,fixed wire 11B* 218159700 A B C Spacer-shelf...
  • Page 10 Publication No. FRS26ZRG 5995325809 CONTROLS 07/99...
  • Page 11 FRS26ZRG Publication No. 5995325809 CONTROLS A = FRS26ZRG (FRS26ZRGB8) B = FRS26ZRG (FRS26ZRGD8) C = FRS26ZRG (FRS26ZRGW8) POS. NO PART NO DESCRIPTION 215028605 A B C Knob-damper control 5308000010 A B C Fan Blade,red 5308000124 A B C Ring-fan orifice 5300157666 A B C Bushing-motor mtg,(2)
  • Page 12 Publication No. FRS26ZRG 5995325809 SYSTEM 07/99...
  • Page 13 FRS26ZRG Publication No. 5995325809 SYSTEM A = FRS26ZRG (FRS26ZRGB8) B = FRS26ZRG (FRS26ZRGD8) C = FRS26ZRG (FRS26ZRGW8) POS. NO PART NO DESCRIPTION 218787900 A B C Condenser 5303208866 A B C Spacer-cond tube,black 5303289026 A B C Spacer-tube 5303289029 A B C Clip-cond mtg,(4) 218679603 A B C...
  • Page 14 Publication No. FRS26ZRG 5995325809 DISPENSER 07/99...
  • Page 15 FRS26ZRG Publication No. 5995325809 DISPENSER A = FRS26ZRG (FRS26ZRGB8) B = FRS26ZRG (FRS26ZRGD8) C = FRS26ZRG (FRS26ZRGW8) POS. NO PART NO DESCRIPTION 5318582501 A B C Tube-water inlet,93" ,plastic, cut-to-size 218832301 A B C Tube-water inlet,inlet valve ,to filter 218859901 A B C Tube-water inlet,inlet valve ,to filter 218949201...

  • Page 16: Ice Container

    Publication No. FRS26ZRG 5995325809 ICE CONTAINER 07/99...
  • Page 17 FRS26ZRG Publication No. 5995325809 ICE CONTAINER A = FRS26ZRG (FRS26ZRGB8) B = FRS26ZRG (FRS26ZRGD8) C = FRS26ZRG (FRS26ZRGW8) POS. NO PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice 5304404346 A B C Drum-ice disp 218815400 A B C...

  • Page 18: Ice Maker

    Publication No. FRS26ZRG 5995325809 ICE MAKER 07/99...
  • Page 19 FRS26ZRG Publication No. 5995325809 ICE MAKER A = FRS26ZRG (FRS26ZRGB8) B = FRS26ZRG (FRS26ZRGD8) C = FRS26ZRG (FRS26ZRGW8) POS. NO PART NO DESCRIPTION 5318582501 A B C Tube-water inlet,93" ,plastic, cut-to-size 218832301 A B C Tube-water inlet,inlet valve ,to filter 218859901 A B C Tube-water inlet,inlet valve ,to filter...

  • Page 20: Wiring Schematic

    Publication No. FRS26ZRG 5995325809 WIRING SCHEMATIC 07/99...

  • Page 21: Wiring Diagram

    FRS26ZRG Publication No. 5995325809 WIRING DIAGRAM # = Fast-moving Parts 07/99 * = Non-Illustrated Parts...
