PRODUCT NO.
BASE MODEL NO.
FRS26ZSHB0
FRS26ZSH
FRS26ZSHW0
FRS26ZSH
MARKET
North America
WIRING DIAGRAM - # 218875901
OWNER'S GUIDE - # 218910000
SERVICE DATA SHEET - # 218909400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
stainless/black
R134a System
stainless/white
Publication No.
5995324331
990604
-EN/SERVICE /KB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZSH
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26ZSH

Summary of Contents for Frigidaire FRS26ZSH

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26ZSHB0 FRS26ZSH R134a System stainless/black FRS26ZSHW0 FRS26ZSH R134a System stainless/white MARKET North America WIRING DIAGRAM - # 218875901 OWNER’S GUIDE - # 218910000 SERVICE DATA SHEET - # 218909400 SIDE BY SIDE REFRIGERATOR 101 Masters Blvd.
