General Overview

2.1. EVB Top View

The following figure illustrates the top view of the EVB.
Table 1: Interfaces of LG69T (AA) EVB
SN. Part No.
A D301, D302
B J201
C S101
D J101
LG69T (AA)_EVB_User_Guide
I
H G F
Figure 1: Top View of LG69T (AA) EVB
Description
Indication LEDs
Micro-USB to UART interface
Power switch
5 V power interface
