Interface Applications
3.1. Micro-USB to UART Interface (J201)
Micro-USB to UART interface can supply power to the EVB, and also supports data transmission.
Micro-USB to
UART Interface
Figure 2: Micro-USB to UART Interface
3.2. GNSS Antenna Interface (J401)
The GNSS antenna interface is used to connect an external passive or active GNSS antenna.
LG69T (AA)_EVB_User_Guide
