Model assembly
2. Using the included double sided tape, adhere the vertical
stabilizer to the fuselage as shown in the diagram.
3. With the fuselage inverted, secure the installed horizontal
and vertical stabilizers to the fuselage using the included
HKM 3.0x26mm screws.
Secure the rudder pushrod using the KA2.0x12mm screws.
Wing installation
1. Slide the two wing halves onto the wing spar.
HKM3.0*26mm
KA2.0*12mm
05
