5 - Electronics specifications

The Optimo Ultra Compact are compatible with the Cooke /i Technology version 3.0 (June 2012) and are ARRI LDS2 ready.
Updates of the embedded software can be found at https://www.angenieux.com/service-and-support/#downloads or by
contacting your distributor. Use the cable 66068093AA to connect the lens to the USB port of the computer for software update and
focus or iris data adjustments during lens maintenance.
Camera connector
External connector
If you are facing communication problems between the camera and the lens:
- If the lens is connected with the Lemo connector, unplug it, wait few seconds and reconnect it
- If it is still not working, switch off the camera or the external viewer
- Disconnect the lens
- Reconnect the lens with the camera or the external device
- Switch the camera or the external device back on
- If the problem continues, contact your local reseller or Angénieux international customer support at:
angenieuxservice@fr.thalesgroup.com
11
4 pins on PL mount
LEMO 4 pins connector EGB00304CLL
Voltage Consumption
9-42 V About 50 mA / 12V
9-42 V About 50 mA / 12V
