Team C TS4 Manual page 6

A
-
Diff
5 Bag
x2
T04040 M2.5x6 Screw
...............12
A
-
Mid CVD
6 Bag
Center Front
T02100 5x10x4
86000
T04041
5.1x8x0.2
16T gear
TS4032
Screw
M3x8
Cement
TS4033
Screw
M3x8
Cement
A
-
Diff
7
Bag
TR4059 M3x10
TR4059 M3x8
TR4059 M3x10
Assemble as many times as specified
x2
All manuals and user guides at all-guides.com
T04040 M2.5x6
30000# for Front
10000# for Rear
TS4032
105mm center front CVD
86000
5.1x8x0.2
T04041
16T gear
TR4059 M3x8
TR4002
Front Gear-box-cover
Apply threadlocker(screw cement)
Screw
Cement
TS4033
105mm center rear CVD
T02100 5x10x4
TR4059 M3x8
TR4059 M3x10
3
T04040 M2.5x6
x1
TS4032/TS4033 M3x8 Screw
...............2
86000 5.1x8x0.2 Washer
..................2
T02100 5x10x4 Ball Bearing
...............4
Center Rear
TR4003
Rear Gear-box-cover
TR4059 M3x8 Screw
TR4059 M3x10 Screw
.........4
.........6
