Team C TS4 Manual page 12

Front Suspension
L
18
R
C
-
Bag
T04002
T04002
Front arm mount-F
L
R
TR4059 M3x10 Screw
...............2
T04034 3x48.5 Arm shaft
..................2
C
-
Turnbuckle
Bag
19
T04014
T04024 3x45
T04014 4.8mm Ball End-Long
......8
T04024 3x45 Turnbuckle
............2
TS4034 3x51 Turnbuckle
............2
Assemble both Left and Right
L
R
All manuals and user guides at all-guides.com
Brace bushing
TR4059
M3x10
4.0mm
TS4035 3x56
T04014
Ture-to -scale diagram
1:1
T04034 3x48.5
1:1 x1
3x51 Turnbuckle
Front upper Rod-R
1:1 x1
3x51 Turnbuckle
1:1 x2
3x45 Turnbuckle
Assemble as many times as specified
x2
9
Front upper Rod-L
29.5mm
29.5mm
Steering Rod
24mm
