VESDA-E VEP-A10-P
Product Guide
VEP-A10-P
(4 Pipes)
April 2016
Document: 22071_11
Part Number: 30311

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VESDA-E VEP-A10-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Xtralis VESDA-E VEP-A10-P

Summary of Contents for Xtralis VESDA-E VEP-A10-P

  • Page 1 VESDA-E VEP-A10-P Product Guide VEP-A10-P (4 Pipes) April 2016 Document: 22071_11 Part Number: 30311...
  • Page 3 You acknowledge that you have not relied on any oral or written information, representation or advice given by or on behalf of Xtralis or its representatives.
  • Page 4 VESDA-E VEP-A10-P Product Guide Scope The VESDA-E VEP-A10-P Product Guide provides a comprehensive description of the VESDA-E VEP-A10- P detector and its accessories. This guide introduces the VEP-A10-P features, technical specifications and gives an understanding of its components and their function. You will also find instructions on installing, cabling and powering up the detector.
  • Page 5 This Xtralis product incorporates a laser device and is classified as a Class 1 laser product that complies with FDA regulations 21 CFR 1040.10. The laser is housed in a sealed detector chamber and contains no serviceable parts.
  • Page 6 The minor low and minor high flow thresholds should be set at 85% and 115% respectively The flow through the detector predicted by ASPIRE must be greater than 20 L/m. Product Listings Regional approvals listings and regulatory compliance vary between product models. Refer to www.xtralis.com for the latest product approvals matrix. Document: 22071_11 Part Number: 30311 www.xtralis.com...
  • Page 7 Managing the Exhaust Air Installation Prepare the Detector Mounting Wiring Powering Up Installation Checklist Preliminary System Check Configuration Communication between Xtralis VSC and the detector Connecting to the Detector Security Commands Configuration Options Factory Default Settings Commissioning AutoLearn Smoke AutoLearn Flow...
  • Page 8 VESDA-E VEP-A10-P Product Guide Smoke Test Air Sampling Test Results Glossary Index www.xtralis.com...
  • Page 9 VESDA-E VEP-A10-P Product Guide Introduction The VESDA-E VEP-A10-P is an aspirating smoke detector (ASD) that provides very early warning of fire conditions by drawing air samples through an air sampling pipe network. Figure 1-1: VESDA-E VEP-A10-P Aspirating Smoke Detector The detector easily interfaces with fire warning and fire suppression release systems, and can be integrated into a building management system (BMS).
  • Page 10 VESDA-E VEP-A10-P Product Guide This page is intentionally left blank. www.xtralis.com...
  • Page 11 A button allows the user to Reset or Disable the detector. In addition an LCD displays detector status including smoke level and a smoke level bar graph, alarm thresholds, trouble status, % airflow level, normalization status and filter life used. www.xtralis.com...
  • Page 12 Controls: Reset and Disable button. Touch-screen featuring a limited set of additional controls and lookup tools. 2.3.1 Status LEDS The VESDA-E VEP-A10-P detector features a range of LED Indicators which illuminate when their respective activation conditions are met. Table 2-1: LED Indicators Symbol...
  • Page 13 The Airflow screen displays the flow level for each of the sampling pipes that are in use. Sampling pipes that have been deactivated are identified with a cross. Note: Refer to Section 3.3 on page 17 for further information on Sampling Pipe configuration. www.xtralis.com...
  • Page 14 LED starts flashing (approximately 15 seconds), then release the button. Cancel the AutoLearn or Normalization functions by pressing and holding the AutoConfig button for 5 seconds. The LED will turn off. If AutoLearn is halted, the flow and smoke thresholds will be left at the previous settings. www.xtralis.com...
  • Page 15 A password is required to access the detector via WiFi connection. It is initially set using Xtralis VSC during configuration with the USB port, and the user is required to enter it when creating a WiFi connection profile in Xtralis VSC.
  • Page 16 Gateway function of the VEP-A10-P The VEP-A10-P detector also provides a gateway to the VESDAnet for a PC running Xtralis VSC connected to the VEP-A10-P via Ethernet, USB or WiFi. Refer to the VESDA Communications Guide for further information on VESDAnet network connectivity.
  • Page 17 Weight 4.1 kg (9.1 lb) Operating Conditions Temperature: Please consult your Xtralis representative for Ambient: 0°C to 39°C (32°F to 102°F) information on operation outside these parameters Sampled Air: -20°C to 60°C (-4°F to 140°F) or where sampled air is continually above 0.05% Tested to: -20°C to 55°C (-4°F to 131°F)*...
  • Page 18 Maintenance and Major Fault Maintenance Aids Filter and flow monitoring Event reporting via VESDAnet and event log Table 2-4: Ordering Information VESDA-E VEP-A10-P Detector VEP-A10-P (4 Pipes) Exhaust Adaptor US VSP-961 Note: Refer to Section Table 7-2 for the spare parts list.
  • Page 19 1.34 34.0 1.34 34.0 1.34 34.0 1.34 26.5 1.04 J 350.05 13.78 224.0 8.82 230.2 9.06 M 135.48 N 132.28 5.21 28.5 1.12 35.0 1.38 45.0 1.77 127.0 143.0 5.63 26.0 1.02 Figure 2-9: Front, top, bottom and side dimensions www.xtralis.com...
  • Page 20 VESDA-E VEP-A10-P Product Guide inch 17.5 0.69 315.0 12.4 17.5 0.69 D 144.99 5.71 77.2 3.04 Figure 2-10: Rear dimensions with Mounting Bracket www.xtralis.com...
  • Page 21 VESDA-E VEP-A10-P Product Guide inch 224.0 8.82 112.0 4.41 40.9 1.61 D 268.39 10.57 40.71 20.25 183.5 7.22 20.25 Figure 2-11: Rear Dimensions with hole locations for direct mounting www.xtralis.com...
  • Page 22 VESDA-E VEP-A10-P Product Guide This page is intentionally left blank. www.xtralis.com...
  • Page 23 Square off and de-burr the end of the sampling air pipes, ensuring the pipes are free from debris. Determine the pipe inlet ports to be used. Refer to Table 3-1 below for details. Remove the plugs from only those pipe inlet ports intended for use. To remove the plug, place a large www.xtralis.com...
  • Page 24 For example, where pressure differences exceed 50 Pa, or where hazardous substances are present inside the protected environment. Return air pipes need to be as short as possible to minimize the effect of airflow impedance in the return air pipe network. www.xtralis.com...
  • Page 25 VESDA-E VEP-A10-P Product Guide Installation The VEP-A10-P detector is shipped with the following components: 1 VESDA-E VEP-A10-P detector Installation Sheet Mounting bracket Mounting template for directly mounting the detector to the mounting surface Exhaust Adaptor (US only) 1 End of Line resistor for the monitored GPI Check all components for damage and refer any concerns to your authorized representative.
  • Page 26 Refer to Section 4.2.2 for further information. Direct mounting: A minimum clearance of 20 mm (0.8 in.) is required between the detector and a wall or obstruction, on both sides of the detector. Refer to Section 4.2.3 for further information. Figure 4-4: Mounting location www.xtralis.com...
  • Page 27 2. Open the front door and remove the fascia. Refer to Sections 7.2 on page 80 and 7.4 on page 84 for further information. Figure 4-5: Detector with fascia removed 3. Take the top and bottom covers off. To do this, press the tabs marked A and B in Figure 4-6. www.xtralis.com...
  • Page 28 A Top cover retaining tabs B Bottom cover retaining tabs Figure 4-6: Tabs used to remove top and bottom cover 4. Detach the tethers, Figure 4-7 and Figure 4-8. (You can leave the cables from the detector to the fascia connected.) Figure 4-7: Detaching the tethers www.xtralis.com...
  • Page 29 VESDA-E VEP-A10-P Product Guide Figure 4-8: Detector with tethers detached 5. Detach the front door from the fascia by removing pin A from the hinge (Figure 4-9, Figure 4-10). Leave pin B in place – do not remove it. www.xtralis.com...
  • Page 30 VESDA-E VEP-A10-P Product Guide Figure 4-9: Removing door hinge pin A Figure 4-10: Detaching door www.xtralis.com...
  • Page 31 Rotate the detector 180 degrees. c. Rotate the door 180 degrees and place it next to the right side of the fascia. 7. Replace the door hinge pin. (Figure 4-12, Figure 4-13) Figure 4-11: Rotate detector and door and move door to right side of fascia www.xtralis.com...
  • Page 32 VESDA-E VEP-A10-P Product Guide Figure 4-12: Replacing the door hinge pin - showing correct positioning of door and pin www.xtralis.com...
  • Page 33 Figure 4-14: Correct positioning of door hinge pin when fully in place 8. Re-attach the tethers. Attach at the slots circled in Figure 4-15. Position the tethers in the slots and pull up as shown in Figure 4-16. Figure 4-15: Re-attach tethers at circled positions www.xtralis.com...
  • Page 34 Figure 7-8. 11. The detector is now inverted. The display should be upright while the exhaust vent is at the top and sampling pipe inlets at the bottom. The electrical connections and filter should be accessible by opening the door. www.xtralis.com...
  • Page 35 Mounting bracket Keyholes Figure 4-18: Mark keyholes 3. Insert two screws into the mounting surface at marked positions (Figure 4-19). 4. Slide plate onto the mounting screws and tighten them with a screwdriver (B). Legend Mounting bracket Screwdriver Figure 4-19: Tighten screws www.xtralis.com...
  • Page 36 7. Open the door on the front of the detector (Figure 4-22). Refer to Section 7.2 on page 80 for further information on how to open the door. 8. Insert and tighten the locking screw (A). This secures the detector to the mounting bracket. Legend Locking screw Figure 4-22: Locking Screw www.xtralis.com...
  • Page 37 For metric pipes, cut the pipe to the inner depth line marked on the mounting template. For imperial pipes, fit the pipe adaptor (C) and cut the pipe to the outer depth line marked on the mounting template. 7. Position electrical conduit (D) on the marked center lines. www.xtralis.com...
  • Page 38 Position the right keyhole on the rear of the detector over the head of the right screw (A) (Figure 4-27). Upright Inverted Detector Detector Figure 4-27: Position detector over screw Slide the detector to the left, or to the right for inverted detectors, to lock the detector on the screw (Figure 4-28). www.xtralis.com...
  • Page 39 Rotate the detector anticlockwise, or clockwise for an inverted detector, to lock the detector on to the screw (Figure 4-30). Upright Inverted Detector Detector Figure 4-30: Rotate the detector 12. Insert an M4 screw at the small end of the detector’s bottom-left, or bottom-right for an inverted detector, keyhole (Figure 4-31). www.xtralis.com...
  • Page 40 VESDA-E VEP-A10-P Product Guide Upright Detector Inverted Detector Figure 4-31: Locking screw 13. Tighten the top and bottom screws. 14. Insert the pipes and electrical conduit. www.xtralis.com...
  • Page 41 A10-P. 4.3.1 Cabling Inlets The VESDA-E VEP-A10-P contains four inlets for power, relay and network cabling, located on the upper and lower sides of the detector base. The holes have a diameter of 26 mm (1.02 inch). Note: To maintain the specified IP rating, cable glands or conduit must be used.
  • Page 42 Attention : Le détecteur de fonctionnement lorsque la tension d'alimentation DC est en dehors de la plage de tension spécifiée peut endommager les composants internes. Pour plus d'informations, se reporter au notice descriptive du produit à la page 11. www.xtralis.com...
  • Page 43 The USB port is used for initial configuration and local maintenance or servicing of the VEP-A10-P using a PC installed with Xtralis VSC software. Install Xtralis VSC prior to connecting the VEP-A10-P to the PC or Laptop. This ensures that the required USB drivers are present.
  • Page 44 Figure 4-35: Example closed loop VESDAnet network The VESDA-E VEP-A10-P detector is shipped with the VESDAnet A and B terminals looped. Remove the A and B links prior to connecting the detector to the VESDAnet. If the detector is not to be networked with other devices, then do not remove the A and B links.
  • Page 45 6 are permanently set for Urgent Fault and Fire 1 respectively. Table 4-22 below illustrates the default assignments of functions (conditions) to relays and summarizes the default behavior of each relay. Section 5.5.10 describes how to configure the relay behavior using Xtralis VSC. It is possible to assign more than one condition to a relay.
  • Page 46 Energizes when the Action alarm is Fully initiated. configurable Fire 1 Energizes when the Fire 1 alarm is initiated. Fire 1 cannot be removed. Other conditions can be added. Fire 2 Energizes when the Fire 2 alarm is initiated. Fully configurable www.xtralis.com...
  • Page 47 A 10K end of line resistor is used to allow the detector to monitor for open circuit faults in the wiring from the detector to the contact. Refer to Section 4.3.11 for information on correct wiring of the End of Line resistor. www.xtralis.com...
  • Page 48 “Mains OK”) EOL* = Normal (NC) Short = Fault Open = Wiring Fault (NO) EOL* *EOL: End of Line Resistor This shows normal operation (no fault). The power supply’s fault reporting relay is energized. Figure 4-38: Input/Output Loop Module with EOL www.xtralis.com...
  • Page 49 Of Line (EOL) resistor is correctly installed. Refer to Section 4.3.8 on page 41 for further information. Legend External device (1 to N) End of Line Resistor at device end of wiring GPI Pin 1 GPI Pin 2 Figure 4-39: Power Supply Connection Diagram www.xtralis.com...
  • Page 50 Detector set to Fan Speed 1 0.34 0.43 Detector set to Fan Speed 5 0.42 0.48 Other 24V Loads Total Total Normal Hours Alarm Hours Normal Capacity Alarm Capacity Total Capacity = Normal + Alarm Multiply by battery factor X1.25 www.xtralis.com...
  • Page 51 (Figure 4-33). This process must only be performed by Xtralis accredited personnel. If the system fails to power up, check all power wires are secured to their terminals and that the polarity is correct.
  • Page 52 The adhesive tape has been removed from the exhaust port. Ensure that the exhaust pipe (if fitted) is NOT glued. The protective film has been removed from the display. The air sampling pipework has been installed and checked as per the site plans. www.xtralis.com...
  • Page 53 To perform the preliminary system check: Power up the detector by connecting the power supply to the Power In terminal. Check that the display is functioning. Check that the aspirator is functioning by determining whether air is being expelled from the exhaust port. www.xtralis.com...
  • Page 54 VESDA-E VEP-A10-P Product Guide This page is intentionally left blank. www.xtralis.com...
  • Page 55 For example, the installer would connect directly to a VEP-A10-P using the USB port with a laptop running Xtralis VSC in order to configure the detector to enable Ethernet or WiFi, the parameters of which could be unique for each installation. A connection profile would need to be defined for the temporary USB connection, and then for the permanent connection using VESDAnet, Ethernet or WiFi.
  • Page 56 Figure 5-1: Connection Manager 2. Select Add. The Add Connection dialog is displayed (Figure 5-2). Figure 5-2: Add Connection 3. Select the VESDAnet connection option, then select Next. Adding a USB Connection 1. Select USB, then select Next (Figure 5-3). Figure 5-3: Select USB www.xtralis.com...
  • Page 57 The IP address and password of the detector is configured in the Ethernet or WiFi options section during initial setup with a USB connection. Refer to Section 5.5.3 on page 61 or 5.5.4 on page 63 for further information. Figure 5-6: Enter IP Address www.xtralis.com...
  • Page 58 VESDA-E VEP-A10-P Product Guide 3. Enter a unique name for the Connection or accept the pre-generated name, then select Finish (Figure 5-7). Figure 5-7: Enter a Connection Name www.xtralis.com...
  • Page 59 5.2.1 Connecting to a detector via USB Direct connection between the detector and the PC installed with Xtralis VSC can be made using a Type A to Type B USB interface lead. Figure 5-8: Connecting to a detector via USB Connect to a detector using Xtralis VSC 1.
  • Page 60 Connect to a detector using Xtralis VSC 1. Using the normal building network connection process, connect the PC to the network. 2. Add an Ethernet / WiFi connection using Connection Manager in Xtralis VSC. Refer to Section 5.1.2 for further information.
  • Page 61 VEP-A10-P must be physically connected to the VESDAnet, as described in Section 4.3.5. another VESDA-E detector can be used as a gateway to communicate between the PC with Xtralis VSC and any device connected to the VESDAnet. Legend PC or Laptop...
  • Page 62 When accessing the VEP-A10-P detector via Xtralis VSC, user functionality is initially limited. For additional privileges, the user must log in to the detector using an 4 digit numeric PIN code. In Xtralis VSC, select Logon from the Connection menu and enter the PIN.
  • Page 63 The following commands are able to be issued to the detector. As indicated below in Table 5-2, a small number of basic commands can be executed from the detector via buttons, while the full range of commands can be executed using the Xtralis VSC software. Table 5-2: Detector Commands...
  • Page 64 Software Detector Start AutoLearn Flow In Xtralis VSC you will be prompted to set the period of time that the environment is monitored to allow the system to decide what flow thresholds are most appropriate. When the AutoLearn has finished, the flow thresholds are overwritten.
  • Page 65 VESDA-E VEP-A10-P Product Guide Table 5-2: Detector Commands (continued...) Command Description Execute From A button Xtralis VSC on the Software Detector Start Minor Fault Test Generates a minor fault on the detector and de- energizes the fault relay for 2 minutes. Start Alarm Test...
  • Page 66 Network Name: The name of the VESDAnet network. (The user can leave this blank if desired.). Location: A description of the physical location of the detector. This name will appear on Xtralis VSC and on the LCD display of the A10 model detector.
  • Page 67 Loop Open Ended on This Device: This should be checked if the network has been wired so either VESDAnet port A or VESDAnet B is not connected on this detector. (Xtralis recommends that VESDAnet ports A and B are always connected so this option should normally not be checked.).
  • Page 68 Static IP Address Configuration IP Address: IPV4 static address. This address must be used when creating a connection profile for the detector in Xtralis VSC. The default IP address is 192.168.0.200. This allows direct connection between a PC or Laptop and the VEP-A10-P using a standard Ethernet lead.
  • Page 69 Mask and Default Gateway fields are disabled. When the detector is joined to the network, the IP address that has been allocated to the detector by the DHCP server can be viewed on the detector status screen in Xtralis VSC by using a USB connection. Static IP Address Configuration IP Address: IPV4 static address...
  • Page 70 Day / Night Changeover Time: The settings for the timing of the threshold changeover. Holidays: The settings used to define a holiday period. Use the dropdown calendars to choose the start and end times of the holiday (or break) period. Night time thresholds are used during the holiday period. www.xtralis.com...
  • Page 71 Pipes in Use: The pipes that are actually being used. Refer to Section 3.3 on page 17 for further information. Aspirator: Select the required Aspirator Speed setting 1 through 5, as determined using ASPIRE. 5.5.7 Filter Option The Filter option page allows you to define the time period after which a filter fault will be generated. www.xtralis.com...
  • Page 72 VESDA-E VEP-A10-P Product Guide Figure 5-18: Filter Options Service Interval (days): The time period after a new filter is installed at which non urgent fault "Filter smoke- dust limit nearly exceeded " (Fault 767) will be generated. www.xtralis.com...
  • Page 73 Delay: The length of time between the measurement of the external smoke level by the reference detector and the internal subtraction of this smoke level from the VEP-A10-P smoke level. Dilution Factor: The percentage of the reference signal to be subtracted from the VEP-A10-P. www.xtralis.com...
  • Page 74 Table 5-3: GPI Operation Function State Change External Reset Unmonitored GPI The detector resets on a 0 VDC to 5 VDC Reset rising edge. Closed Monitored GPI Open The detector resets on a contact closure. Reset www.xtralis.com...
  • Page 75 The detector is enabled on a 5 VDC to 0 VDC falling edge. Monitored GPI Closed Disabled The detector is held disabled while Open contact is closed. Enabled The detector is enabled when the contact opens. Note: No alarms are signalled while the detector is disabled. www.xtralis.com...
  • Page 76 When the detector is disabled or set to standby via the GPI, the status cannot be changed through the normal enable / disable function on the front panel or via Xtralis VSC or a remote display. Refer to Section 2.3.2 on page 6 for further information.
  • Page 77 Latching can be enabled for any alarm condition or for urgent or minor fault by checking the corresponding latching checkbox to the right of the condition. www.xtralis.com...
  • Page 78 VESDA-E VEP-A10-P Product Guide 5.5.11 Button Lockout Options Figure 5-22: Button Lockout Options Lockout: The Reset and Disable functions cannot be executed using the detector front panel button if the corresponding checkbox is ticked." www.xtralis.com...
  • Page 79 Fire 1 0.20 % obs/m 0.010 % obs/m 2.0 % obs/m (0.0063 % obs/ft) (0.0031 % obs/ft) (0.625 % obs/ft) Fire 2 2.0 % obs/m 0.02 % obs/m 20.0 % obs/m (0.625 % obs/ft) (0.0063 % obs/ft) (6.25 % obs/ft) www.xtralis.com...
  • Page 80 Filter Service Interval 731 days 1 day 3655 days Referencing Referencing Enabled Unchecked Unchecked Checked Detector Blank Zone 1 Zone 254 Delay 2 minutes 0 minutes 15 minutes Dilution Factor 100% 100% General Purpose Inputs GPI Function Reset (Unmonitored) www.xtralis.com...
  • Page 81 15 minutes 16 days The Xtralis VSC software forces the user to move the detector to a valid zone number. The user must set the password the first time. There is no default password. Default value set in factory. Not modified by return to factory defaults command.
  • Page 82 VESDA-E VEP-A10-P Product Guide This page is intentionally left blank. www.xtralis.com...
  • Page 83 For code-specific information, see Codes and Standards Information for Air Sampling Smoke Detection on page iii. AutoLearn Smoke AutoLearn Smoke is initiated by using Xtralis VSC or the AutoConfig button located on the main board of the detector. During the AutoLearn Smoke process, the detector determines the average smoke and peak smoke obscuration levels and sets suitable alarm thresholds for the operating environment.
  • Page 84 AutoLearn Flow AutoLearn Flow process is initiated within Xtralis VSC or the AutoConfig button located on the main board of the detector. During the AutoLearn Flow process, the detector normalizes the airflow and then monitors over time the average, maximum and minimum air flow levels and sets suitable air flow thresholds that will not give rise to nuisance flow faults due to normal flow variations.
  • Page 85 4.3.6 and 5.5.10 for further information. For example, standby mode may be also signaled as an additional condition on the Fault Relay (Relay #3). To set the detector to Standby mode using Xtralis VSC, select Go to Standby from the Device menu. The Disabled LED will blink and the aspirator will turn off.
  • Page 86 Open the Front Door 1. Release the door latch by inserting a thin screwdriver into the hole at the bottom left of the door and firmly pushing perpendicular to the door surface. 2. Pull the door open. Figure 7-1: Open the door www.xtralis.com...
  • Page 87 1. Open the front door. Ensure that the area around the filter is free of lint and dust before removing the filter. Refer to Section 7.2 on page 80 for further information. 2. Press on release mechanism in the direction arrowed (Figure 7-2). Figure 7-2: Release Filter www.xtralis.com...
  • Page 88 4. Lift the filter out of the detector case (Figure 7-4). Figure 7-4: Remove Filter Reinstall the Filter Note: Ensure that the new filter is free of lint and dust. 1. Tilt the filter towards the left and position its hinge pins in their recess (Figure 7-5). www.xtralis.com...
  • Page 89 VESDA-E VEP-A10-P Product Guide Figure 7-5: Engage hinge pins 3. Tilt the filter to the right. 4. Firmly press, as shown in Figure 7-6, until the filter makes a distinct clicking sound and no additional movement is possible. Figure 7-6: Reinstall the Filter www.xtralis.com...
  • Page 90 Un bracelet doit être raccordé au panneau du détecteur (Figure 7-7). Figure 7-7: Wrist Strap application Remove the Fascia 1. Turn off the 24V DC power to the detector. 2. Remove the two screws along side the door hinge, as shown below in Figure 7-8. www.xtralis.com...
  • Page 91 VESDA-E VEP-A10-P Product Guide Figure 7-8: Fascia removal - remove screws 2. Remove the fascia and allow it to hang by the two tether straps. Figure 7-9: Fascia hanging on two tethers www.xtralis.com...
  • Page 92 3. Disconnect the aspirator cable (A) (Figure 7-10). Figure 7-10: Disconnect the aspirator cable 4. Remove the six screws holding the aspirator to the detector base (Figure 7-11). Figure 7-11: Remove aspirator mounting screws 5. Remove the aspirator perpendicular to the detector body (Figure 7-12). www.xtralis.com...
  • Page 93 VESDA-E VEP-A10-P Product Guide Figure 7-12: Remove aspirator from the detector Reinstall the replacement Aspirator To replace the aspirator, follow the removal procedure in reverse. www.xtralis.com...
  • Page 94 1. Turn off the 24V DC power to the detector. 2. Remove the Filter. Refer to Section 7.3 on page 81 for further information. 3. Remove the four screws holding the chamber to the detector base (Figure 7-13). Figure 7-13: Undo Chamber retaining screws www.xtralis.com...
  • Page 95 VESDA-E VEP-A10-P Product Guide 4. Disconnect the chamber loom from the connector labeled J3 (Figure 7-14). Figure 7-14: Disconnect Chamber Loom 5. Remove the chamber from the detector base (Figure 7-15). Figure 7-15: Remove the Chamber from the detector base www.xtralis.com...
  • Page 96 Looms beside module Air flow sensing module Figure 7-16: Position the gray loom 2. Position the chamber looms (A) and (B) as shown in Figure 7-17. Figure 7-17: Position the Chamber looms www.xtralis.com...
  • Page 97 Figure 7-18: Install the Chamber 4. Secure the four screws which hold the chamber to the detector base (Figure 7-13). 5. Reconnect the loom to J3 (Figure 7-14). 6. Reinstall the Filter. Refer to Section 7.3 on page 81 for further information. www.xtralis.com...
  • Page 98 1. Turn off the 24V DC power to the detector. 2. Open the front door and remove the front fascia. Refer to Sections 7.2 and 7.4 for further information. 3. Disconnect the Sampling Module cable (Figure 7-19). Figure 7-19: Disconnect the Sampling Module cable www.xtralis.com...
  • Page 99 VESDA-E VEP-A10-P Product Guide 4. Press on the lever on the connector to release the catch (Figure 7-20). Figure 7-20: Release the Sampling Module cable 5. Undo the three screws holding the Sampling Module (Figure 7-21). www.xtralis.com...
  • Page 100 VESDA-E VEP-A10-P Product Guide Figure 7-21: Undo Sampling Module screws www.xtralis.com...
  • Page 101 Sampling Module is seated on the pipes in the detector (Figure 7-23). You will feel the module slide onto the pipes. Figure 7-23: Reinstall Sampling Module 2. Tighten the three screws and re-connect the Sampling Module cable (Figure 7-19). www.xtralis.com...
  • Page 102 The detector's internal components are field replaceable. Table 7-2 below provides a complete list of these spare parts and each one's ordering number. Table 7-2: Spare Parts Part No. Description VSP-960 VESDA-E VEP Mounting Bracket VSP-962 VESDA-E VEP Filter VSP-963 VESDA-E VEP Aspirator VSP-964 VESDA-E VEP Chamber Assembly VSP-965 VESDA-E VEP Sampling Module www.xtralis.com...
  • Page 103 Troubleshooting If the VEP-A10-P detector identifies a fault condition, the Fault LED on the front of the detector illuminates and an event containing details of the condition is written to the Xtralis VSC active event list and the detector's event log.
  • Page 104 Xtralis VSC and the date, time, fault number and description of any faults can be viewed. The Xtralis VSC software also displays any current faults in the active event list. The list displays the date and time of the fault, the serial number of the device on which the fault has occurred, the zone number, fault number, and a description of the fault.
  • Page 105 The alarm and fault relay outputs are wired to the fire panel. Test the detector’s Relay outputs connection to the fire panel using the Xtralis VSC Relay Test command. (Turn each relay on/off individually.) See below. Relay 1 Tested (Default assignment = Disable)
  • Page 106 The alarm and fault relay outputs are wired to the fire panel. Test the Remote Display/Relay’s Relay output connections to the fire panel using the Xtralis VSC Relay Test command. (Turn each relay on/off individually.) See below. Relay 1 Tested (Default assignment = Disable)
  • Page 107 VEP-A10-P Detector Commissioning Configuration To record the detector's configuration you can print it using Xtralis VSC. To print the configuration select the detector on the Xtralis VSC tree view at left and choose the Print command on the File menu.
  • Page 108 VESDA-E VEP-A10-P Product Guide This page is intentionally left blank. www.xtralis.com...
  • Page 109 If the cause of a condition is removed (for example, smoke decreases below the threshold) and latching is enabled, the detector “remembers” the condition and holds the corresponding relays and displays in the active state as though the cause of the condition were still active. www.xtralis.com...
  • Page 110 The detector signals that it is in Standby mode using Relay 1. Z Zone A defined area within the protected premises from which an alarm signal can be received. www.xtralis.com...
  • Page 111 5-6, 39, 41, 57, 68-70, 79, 103 cancel AutoLearn flow display module 9, 39, 41 cancel AutoLearn smoke disable EOL resistor 19, 41-43 enable 35, 80, 84, 88 normalize air flow ethernet3, 5, 9, 11, 19, 36-37, 51, 56, 61, 68, 73 rebuild zone list www.xtralis.com...
  • Page 112 3, 36, 41-42, 68, 103 pipe use night-time threshold airflow diameter endcap 17, 77 9, 55, 103 exhaust flow rate 17, 77 isolate 36, 39, 70 inlet pipes inlet ports 17, 19 installation 3, 5-6, 45, 68, 79, 97 length maintenance www.xtralis.com...
  • Page 113 WiFi 5, 9, 11, 56, 63, 68, 73 fault 36, 39 wiring 35, 41-42 fire 36, 39 address loop module isolate FACP options power remote display 9, 60, 97 VESDAnet reset 5-6, 41, 45, 57, 68, 70, 77 www.xtralis.com...
  • Page 114 VESDA-E VEP-A10-P Product Guide zone 58, 60, 79, 103 www.xtralis.com...
