StarTech.com US1GA30SXSC Quick Start Manual

Quick-start guide
USB 3.0 to Gigabit Ethernet Fiber Optic Network Adapter - 1000Base-SX SC
US1GA30SXSC
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com

Package contents

• 1 x network adapter
• 1 x quick-start guide

Requirements

• USB-enabled computer with an available USB 3.0 port
• Any of the following operating systems:
• Microsoft Windows® 10, 8/8.1, 7
• Microsoft Windows Server® 2012, 2008, 2003
• macOS High Sierra (10.13), Sierra (10.12) El Capitan (10.11),
Yosemite (10.10), Mavericks (10.9), Mountain Lion (10.8)
• Linux® kernel 3.5 to 4.11.x, LTS versions only
Operating system requirements are subject to change. For the latest
requirements, please visit www.StarTech.com/US1GA30SXSC.

Product diagram

Power LED
*actual product may vary from photos
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/US1GA30SXSC
Built-in USB 3.0
cable
Fiber optic SC
port
Link and activity LED

Installation

Notes: You may need to restart your computer during the software
installation process. Be sure to save any unsaved material before you
install the software.
1. Connect a multimode SC fiber cable to the network adapter's
Fiber optic SC port and to your fiber network.
2. Connect the built-in USB 3.0 cable on the network adapter to a
USB port on your computer.
Note: If the driver for the network adapter installs automatically,
the installation is complete. If the driver does not install
automatically, you'll need to manually install the driver. Follow the
instructions below for your specific operating system.
Windows
1. If the Found New Hardware dialog box appears on your screen,
close the dialog box or click Cancel.
Note: Once the network adapter is connected to the computer,
it will load a CD-ROM device that contains an executable file that
you can use to install the driver.
2. After the CD-ROM device finishes loading, run the installation file.
3. Complete the on-screen instructions to finish the installation.
Note: You can also download the latest software from the
StarTech.com website,
www.StarTech.com/US1GA30SXSC.
macOS
1. Download the latest macOS drivers from the StarTech.com
website,
www.StarTech.com/US1GA30SXSC.
2. The drivers will be compressed in a .zip folder, extract the
contents of that folder to a location on your computer that's easy
to access, such as your Desktop.
3. Double-click the appropriate installer file for the version of macOS
that you're running, and follow the on-screen instructions to
complete the installation.
Manual Revision: 11/27/2017
